Help CenterPractical Promotional Semi Auto m Type Pallet Film Wrap Machine
Related Products
-
2018 Counting Function Automatic Airport Luggage Wrapping MachineUS$ 2,000 - 6,000MOQ: 1 Set -
Tea Bag Non-woven Bag Packaging MachineUS$ 980 - 1,300MOQ: 1 Set
-
1 kg Packing Machine for Bags Under Sugar /sugar Stick Packing Machine /bags Package MachineUS$ 980 - 1,300MOQ: 1 Set
-
Automatic Detergent Powder Packaging MachineUS$ 980 - 1,300MOQ: 1 Set
-
Low Cost Powder Packing Machine,automatic Packing Machine, Automatic Pouch Packing MachineUS$ 980 - 1,300MOQ: 1 Set
Pallet wrapping machine description:
Mob/whatsapp/wechat:008618037329034
Email:mona(at)
Skype:monamachinery
pallet wrapping machine use the LLDPE stretch film/wrapping film as packing
material.The machine is widely used to wrap tray or pallet goods.This type machine can pack different shape goods.Take the advantage of the nerviness and autohension of the film,fix the goods and pallet together.So that the goods will never bale off or fall down.To protect the machine from dust,damp,damaged,and scattering.Also after wrapped with pallet,the goods is easy to carry.
Pallet wrapping machine features:
1.PLC Microcomputer programmable control.
2.Wrapping layer,times,and strengthening layer can be adjusted 0-9 layers.
3.LED display screen.
4.Simply press the run button,can complete the whole packaging process.
5.Jacking System is the latest international level with High tensile strength and transport structure. Tension is big, long service life, no noise, no fuel.
6.Optoelectronic switch,measuring the height of the goods automatically.
7.Selected electrical control components, high reliability.
8.Operate by hand or itself.
9.Turntable is Soft start and slow stop adopt frequency control to avoid the goods fall down caused by inertance.
10.You can adjust tension of the film according to the characteristics and your needs.
Pallet wrapping machine parameters:
Model |
MN-7T |
Power |
1.2Kw/AC220V |
Turn Plate Rotational Speed |
0-12turn/min(frequency adjustable) |
Turntable diameter |
1650mm |
Turntable height |
85mm |
Machine weight |
650KG |
Max packing weight |
2000KG |
Max packing height |
2400mm |
Control System
1.PLC programmable control the machine running.
2.The top and bottom layer number of twisting can be set separately.
3.Single strengthen control button, can be at any position of local reinforcement.
4.International panel icon, operation more convenient and simple.
5.Photoelectric switch from dynamic measuring the height of the goods, the top 0-9 seconds time can be set.
6.Automatic/manual switch, reset button and ensure the equipment not misoperation, affect the equipment performance; Protect the security of the operating personnel.
7.Mechanical and photoelectric switch function, the free convenient manipulation of the equipment, to achieve the double insurance, guarantee the equipment under the condition of small fault, the machine does not stop working.
8.Membrane body up and down automatically, realize the roll of film only need to put the goods and start, do not need to plug membrane, time, efficiency is higher. Can be equipped with remote control, convenient operation.
Table drive
1.Wear brand new nylon roller support, low noise operation.
2.Rotary frequency control of motor speed, slow stop automatic reset.
3.Operation panel single origin reset button.
Membrane system
1.Free swing arm, responsive, automatic power pretensioning for membrane (draw ratio 250), the film easy pull; Save two-thirds of consumables.
2.Film guide roller made from seamless steel tube finishing, wear-resisting durable; frequency conversion of pretension rubber roller adopts automatic self-aligning bearing, no noise, stable and reliable running.
3.Adopt double chain structure, membrane frame rate of rise and fall, respectively is adjustable, film feeding speed is adjustable.
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Zhengzhou City, China.You can fly to Zhengzhou airport directly.All our clients,
from home or abroad, are warmly welcome to visit us!
3.Q:How can I get some samples?
A: We are honored to offer you samples.
4.Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end.
Trade Terms:
1.Payment: T/T, LC; 30% deposits; 70% balance before deliverying.
2.Delivery Time: 15-60 days
Why Choose Us?
We make domestic, agricultural and industrial hand sprayers in a huge variety of styles. Established in 1978 and holding an AAA credit rating, our reputation rests on a threefold foundation: our products, prices, and people.
We have a long history and strong technology in this, and use a complete set of advanced equipment and technology. With good performance and novel styles, have become well known at home and abroad.
With our sprayers popular among clients, our "MONA" trademark is famous worldwide. Besides China, our sprayer items are now exported to Hong Kong, the USA, Canada, Central and South America, Europe, Southeast Asia, the Middle East, Africa and Australia, etc.
If you are interested in any of our products, please feel free to contact us for more information. We are looking forward to forming business relations with customers domestically and internationally.
