Professional Double speed automatic good quality meatball machine
Introduction
This machine is used to make chicken meat balls, shrimp balls, pork balls, beef balls, mutton balls, vegetable balls.
The main structure and working principle
1. The machine main including main knife combination, forming gears and, hopper, rotary combination, lubrication waterways combination, transmission system, etc.
the machine food touched parts adopt stainless steel and non-ferrous copper alloy materials, conform to the requirements of the food hygiene, easy to clean. E*ternal plate adopt stainless steel material, appearance, corrosion resistance.
2.working principle
Machine is working, twisted dragon rotary press, make meatballs raw material inside the hopper after molding gear, molding, fork leads do reciprocating motion of the cutting knife, the cutting the rotating balls stuffing, complete the balls.
Technical Parameters:
Model |
MN-380 |
Dimension |
760*355*1220mm |
Power |
1.5kw |
Voltage |
220( single phase ),380V(three phase) |
Capacity |
200-300pcs/min |
Dies of meatball machine |
Big, Middle, Small Dies. |
If you need the matched meatball beating machine,pls refer to the following :
Model |
Voltage |
Power |
Dimension |
Capacity |
weight |
MN—22 |
220V |
2.2kw |
340*330*800mm |
2kg/time |
28kg |
MN—24 |
220V |
2.2kw |
340*330*800mm |
3kg/time |
30kg |
MN—26 |
220V |
2.2kw |
400*400*920mm |
4kg/time |
32kg |
MN—30 |
380V |
5.5kw |
680*400*840mm |
8kg/time |
95kg |
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Zhengzhou City, China.You can fly to Zhengzhou airport directly.All our clients,
from home or abroad, are warmly welcome to visit us!
3.Q:How can I get some samples?
A: We are honored to offer you samples.
4.Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end.
Trade Terms:
- Payment: T/T, LC; 30% deposits; 70% balance before deliverying.
- Delivery Time: 15-60 days
Why Choose Us?
We make domestic, agricultural and industrial hand sprayers in a huge variety of styles. Established in 1978 and holding an AAA credit rating, our reputation rests on a threefold foundation: our products, prices, and people.
We have a long history and strong technology in this, and use a complete set of advanced equipment and technology. With good performance and novel styles, have become well known at home and abroad.
With our sprayers popular among clients, our "MONA" trademark is famous worldwide. Besides China, our sprayer items are now exported to Hong Kong, the USA, Canada, Central and South America, Europe, Southeast Asia, the Middle East, Africa and Australia, etc.
If you are interested in any of our products, please feel free to contact us for more information. We are looking forward to forming business relations with customers domestically and internationally.
