Poultry And Seafood Weight Grading System (10-3000g) 6 Grade Fish Sorting Machine (10g~1200g)
Poultry And Seafood Weight Grading System (10-3000g) 6 Grade Fish Sorting Machine (10g~1200g)
1. Application Scope:
This product is mainly applied to seafood, multi-level sorting livestock and poultry, aquatic products, agricultural products. Such as: shrimp :( crayfish, prawns, shrimp, sword shrimp, pink shrimp, shrimp, shrimp, prawns, shrimp, white shrimp, shrimp, etc.); livestock and poultry :( duck leg, duck wings , duck feet, duck breast, whole frozen ducks and duck related food);
2, the main function:
* Reporting: Built-in reports, statistics, reports can be generated EXCEL format; can automatically generate a variety of real-time data reports, for each nesting population weight and the total weight of the individual statistics, production status at any time hold grip, U disk can store more than one statistics;
* Interface functions: reserved standard interfaces to facilitate data management, networking and PC and other smart device communications;
* Centralized Control: enables a computer / machine interface centralized control of multiple checkweighers machine;
* Parameter Recovery: provide factory parameter settings to function;
3, features:
* Security Waterproof: Waterproof design machine;
* Efficient Economy: multi-level sorting automatic weighing, replace labor, increase efficiency;
* Versatility: machine HMI standardized structure and standardization to be completed by weighing various materials; easy to replace: can store a variety of formulations, product specifications and convenient replacement;
* Operation is simple: Use Willen color HMI, intelligent, user-friendly design;
* Easy maintenance: conveyor easy disassembly, easy installation and maintenance, easy to clean;
* Speed adjustable: variable frequency control motor speed can be adjusted as needed;
* High-speed, high-precision: High-precision digital sensors, sampling speed, high precision;
* Customizable: sorting level can be customized according to customer demand;
* Zero Tracking: manually or automatically cleared, and the dynamic zero tracking;
Technical Data
Model |
MN-220 |
Weighing Capacity |
10~1200g |
Weighing Accuracy |
± 0.5g |
Product dimensions |
(L)30~300mm (W)30~220mm (H)10~150mm |
Weighing Scale Size |
400mm(L)x245mm(W) |
Weigh Sensor |
Double-beam load cell |
Conveying |
Food Belt(Belt Width:220mm) |
Display |
Chinese, English |
Minimum Scale |
0.1g |
Setting Range Weight Value |
press the number keys:0.1g~1200.0g(standard +Over:0.1g difference) |
Setting Range Belt speed |
Standard weight setting:15~60m/min(1m/min spacing) |
Menu |
Standard/Over/Under weight,product name,belt speed etc pre-setting as one unit; Totally 50 units |
Error Message display |
Zero error,photosensor error,setting error,products too close error,product too long error |
IP rating |
In accordance with international IP65 standard |
Construction |
304SUS, Polishing |
Machine Size LxW |
750mm x 580mm |
Machine Size The height from conveyor belt to the ground |
650mm~900mm |
Machine Weight |
Appr.55Kg |
Power Supply |
Single-Phase AC200V~240V |
Other Standard Accessories |
Windshield cover(Colorless and Clear),photosensor |
Other |
Weighing accuracy and speed depend on product shape and other conditionsetc |
