Beer Fermentation Tanks/Fermenting Equipments/Fermenter/Fermentor 5BBl/7BBL/10BBL

Beer Fermentation Tanks/Fermenting Equipments/Fermenter/Fermentor 5BBl/7BBL/10BBL

Beer Fermentation Tanks/Fermenting Equipments/Fermenter/Fermentor

5BBl/7BBL/10BBL

This fermenter is widely used in the fermentation of beer, liquor, wine, milk, acetic acid, microbes, etc.Fermentation system:

1) Glycol cooling jackets on both cylinder and cone

2) Inner wall stainless steel 304, 3mm; surface SUS 304, 2.0mm

3) Dome top, conical bottom 60-72 degree, top manway

4) Insulation: polyurethane 100mm

5) Inside 360 degree CIP washing ball; Inside polishing 0.4-0.6 micron.

automatic pressure relief,working pressure: 1Bar, testing pressure: 2Bar

6) with thermowell and pressure sensor&gauge- safety valve- vacuum valve  3 legs with adjustable bolts

Our catalogue:

Beer selling: beer tower, beer selling tank, stainless steel beer kegs, keg filling, keg washing, bottle filling, bottle washing, capping machine and etc.

Effective volume:200L-10000L
Inner container: SUS304,Thickness 3mm, 2B finished.
Outer container: SUS304, thickness 2mm, Grind arenaceous.
Shell jacket: SUS304, thickness 1.5mm.
Insulation Material: polyurethane, thickness: 80mm.
Ribbon polished for the welded place.
Conical top/ Cylinder/ conical bottom/ shell jacket(one or two sections) / bottom jacket / insulation both on shell and bottom / with adjustable legs.
Connections:level interface/ steam Import and Export/ Pt100 interface/ top manhole / respirator/ Inlet/ Outlet.
