Garlic planter Introduce
This is precision garlic, potato planting machine,the accuracy can reach one hole one seed or one hole multiseeds according to the customer’s request;the distance between hills and the depth are adjustable also.
Can be widely used in plains and hills, east and west regions in scale, mechanization planting garlic, can use single power, by turning to the success of garlic, realize one-time wide range of continuous satisfactory, can realize scale, garlic planting mechanization.
Tractor driven garlic planting machine
I . The machine is effective and reasonable configuration, to ensure the operation process is stable, reliable and efficient.
II. garlic direction of the rapid adjustment, so that garlic up, to ensure the survival rate of planting.
III. intermittent continuous precision species, to ensure that planting line spacing and point species frequency.
IV. planting density and planting uniformity coefficient.
1. quickly adjust the direction of garlic garlic facing up, so that garlic roots down, head up.
2. accurate point species, high efficiency, can improve the efficiency of planting, to achieve the mechanization of garlic sowing.
3. using a separate gasoline power low cost, simple structure, easy to scale operations.
Working efficency
1. line planting consistent coefficient%: ≤ 3.8
2. total row seeding stability coefficient of variation%: ≤ 1.2
3. a turn on the success rate%: ≥ 92%
4. spot depth rate%: ≥ 90%
5. machine straight line offset: ≤ 50mm
6. virtual feeding times: ≤ 50 times / h
7. vibration caused the surface of the garlic beating height: ≤ 10mm
Garlic planter Specification
Item |
Garlic planting machine |
Model |
MN-5 |
Working width |
110cm |
Sowing depth |
5-15cm adjust |
Working rows |
5 rows or customized |
Row spacing |
18-20 cm adjust |
Net Weight |
55kg |
Matched Power |
5.5HP Gasoline motor engine |
Application |
Garlic planting or small potato planting |
