Brief introduction of SB series rice milling machine
1. This SB-series small rice mill is widely used for processing paddy rice into polished and white rice. This series small rice mill has the functions of husking, destoning, milling and polishing.
2.That is the machine can make cleaning, husking, air-blowing and milling in succession, then husk, chaff, runtish paddy and white rice are pushed out of machine respectively, high production and easy operated.
3. We have different model small rice mill with different capacity for customers to choose such as SB-5, SB-10, SB-30, SB-50, etc.
Parameters of SB series rice milling machine
Model |
SB-5 |
SB-10 |
SB-30 |
SB-50 |
Power |
10HP |
22HP |
22HP |
36HP |
Capacity |
400-600kg/h |
600-900kg/h |
1100-1500kg/h |
1800-2300kg/h |
Rubber roller |
Diameter: 180mm |
Diameter: 233mm |
Diameter: 283mm |
Diameter: 254mm |
|
Flat pulley on main shaft |
Fast roller shaft: 160×80mm |
Fast roller shaft: 160×80mm |
Fast roller shaft: 160×80mm |
Fast roller shaft: 160×80mm |
Overall Dimension |
690×670×1400mm |
780×760×1700mm |
1070×760×1760mm |
1050×970×2200mm |
Machine weight: |
130/190KG |
195/285KG |
320/400KG |
630/720KG |
Packing |
Wooden case packing as exports standard |
Wooden case packing as exports standard |
Wooden case packing as exports standard |
Wooden case packing as exports standard |
Working principles of SB series rice milling machine
Paddy firstly enters small rice mill through vibrating sieve and magnet device, then passes rubber roller for hulling. After air blowing and air jetting to the milling room, the paddy finishes the process of husking and milling in succession. Then husk, unripe paddy, and white rice are expelled out of the home use rice milling machine respectively. The dust collector collects the fine rice husk from the rice mill machine.
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Zhengzhou City, China.You can fly to Zhengzhou airport directly.All our clients,
from home or abroad, are warmly welcome to visit us!
3.Q:How can I get some samples?
A: We are honored to offer you samples.
4.Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end.
Trade Terms:
1.Payment: T/T, LC; 30% deposits; 70% balance before deliverying.
2.Delivery Time: 15-60 days
