5TD series Multi crop thresher / Rice,Wheat,sorghum and soybean thresher
5TD series Multi crop thresher / Rice,Wheat,sorghum and soybean thresher
Introduction of sorghum wheat paddy rice thresher
It's main used for threshing of various crops like rice,wheat,corn,soybean,barley,sorghum and millet etc.It can be driven by diesel to set on the tractor, also can be driven by the electric motor according to your needs, easy use high efficiency working.
Component: racks, concave screen, drum, cover, main fan, the second suction fan, motor, or (diesel), vibrating screen, traction-driven device component, it is used to shell many kinds of grains, such as: sorghum, millet, bean, wheat , rice and so on.
Principle of the sorghum wheat paddy rice thresher
When the machine in operation, firstly put the crops into machine from feeder, and the crops will
be rubbed, squeezed, collided and shaken by assembly of rack and screen mesh, then to make
the grain seperated from culm, then flowing out from the screen mesh. Finally, the culm
will be thrown out by centrifugation of roller, and threshing is finished .
Note:The client could choose the machine without motor and with motor, diesel engine gasoline
Main parameter of sorghum wheat paddy rice thresher
Model |
MN-135 |
MN-125 |
MN-100 |
MN-70 |
MN-50 |
Capacity |
1200-1500kg/h |
800-1200kg/h |
750-1000kg/h |
550-600kg/h |
350-400kg/h |
Measurement(mm) |
2400x2670x1530 |
2400x2480x1530 |
2300x2000x1500 |
1070x2060x1340 |
1400x900x1050 |
(leng x width x height) | |||||
Power(kw) |
13-15 |
11-13 |
7.5-11 |
7.5 |
5.5-7.5 |
gross weight(kg) |
500 |
450 |
420 |
260 |
150 |
rotating speed(r/min) |
1000 |
1000 |
1060 |
1200 |
1400 |
wrap angle of the concave |
240 |
||||
