Product Details
Brand Name: | XH | Place of Origin: | China | Model Number: | GR-d |
Application: | Boat | Power Source: | Electric | Capacity: | 50KN |
Product Description
Product Introduction
The boat winch driven by electric motor belongs to a short time working equipment. The boat winch is of two kinds of structures, left-hand and right-hand boat winch which are symmetric. It can be suitable for arranging on the parent ship whose deck are symmetric.
The boat winch is of the functions of hoisting boat by electric, lowering boat by gravity and hoisting boat by manual as well as manual quick lowering device for empty hook. The boat winch is provided with a manual driving unit which can automatically separate, and a interlocking switch. It can avoid the personal injury caused by mis-operation to the maximum.
Technical Data
Model Particulars | D50S* | D50Z* | D63S* | D63Z* | D100S* | D100Z* | ||||||||
Length | mm | 1490 | 1645 | 1535 | 1785 | 1920 | 2080 | |||||||
Height | mm | 1240 | 1240 | 1230 | 1230 | 1380 | 1470 | |||||||
Breath | mm | 855 | 855 | 795 | 795 | 1210 | 1210 | |||||||
Weight | kg | 940 | 1165 | 990 | 1300 | 2980 | 3800 | |||||||
Base dimension | mm | 580×360 | 550×305 | 690×380 | 690×380 | 1330×540 | 1330×540 | |||||||
Max. working load | kN | 50 | 50 | 63 | 63 | 100 | 100 | |||||||
Hoisting load | kN | 28 | 28 | 30 | 30 | 70 | 70 | |||||||
Max./Min. lowering load | kN | 31/15 | 31/15 | 40/12 | 40/12 | 60/25 | 60/25 | |||||||
Wire rope | mm | Φ16 | Φ16 | Φ18~20 | Φ18~20 | Φ22~24 | Φ22~24 | |||||||
Rope capacity | m | 60 | 60 | 65 | 65 | 2×70 | 2×70 |
* S: Life Boat Winch
Z: Rescue Boat Winch
