Below one is PLC controled , operation by TOUCH SCREEN , all the programmer are input in the screen.
GR vacuum tumbler
Keywords: vacuum tumbler
Vacuum massage machine
Meat machine
Meat marinating machine
Product description:
Vacuum tumbler Machine can provide a physical processing of meat energy transformation, an indispensable technology of meat processing, and is assort of available approach to accelerate souse speed, proceed mechanical treatment to diced meat through rolling and kneading, increase the abstraction of salt soluble albuminoidal, improve the rate of manufacture and product quality.
--Propeller is designed distinctively, positive rotation for rolling, kneading and knocking, inversion for massaging/
--Control positive rotations, inversion, intermission, charge, rotation rate, vacuum and atmospheric pressure according to customer’s
requirement and could realize independent assortment. Adopt PLC, soft startups; touch screen control that can store 100 formulations.
--Vacuum intake. Meat output in inverse rotation. Breathing-style process designed to make sure rolling and kneading under both vacuum
and regular state to shorten processing time. Bigger intake hole can put in powder or other additives easily.
-- have two kinds, one is buttons operation; the other is PLC controlled with touch screen.
You can set the parameters, the vacuum time, speed, positive and reserve rotation times, total time can be set on the touch screen.
-- GRHT250 model can be turnover for the drum; the drum also can be taken out with wheel.
Mode |
External Dimension mm |
Volume L |
Capacity kg |
Power kw |
Vacuum mpa |
Rotation Speed rpm |
Weight kg |
|||
motor |
Vacuum Pump |
Double speed |
Single |
Regulating speed |
||||||
GR20 |
945×515×800 |
20 |
10 |
0.37 |
0.25 |
-0.09 |
/ |
9 |
1.8-9 |
130 |
GR50 |
1300×860×940 |
50 |
20 |
0.45/0.75(0.55) |
0.55 |
6/12 |
8 |
4-12 |
200 |
|
GR100 |
1370×860×940 |
100 |
20-50 |
0.45/0.75(0.55) |
250 |
|||||
GR200 |
1300×915×1265 |
200 |
50-100 |
0.45/0.75(0.55) |
285 |
|||||
GR500 |
1580×1115×1530 |
500 |
200-300 |
0.85/1.5(1.1) |
1.1 |
440 |
||||
GR1000 |
2190×1300×1720 |
1000 |
400-600 |
1.5/2.4(1.5) |
1.1 |
6/12 |
6 |
730 |
||
GR1600 |
2225×1500×1940 |
1600 |
800-1000 |
2.2/3.3(3) |
2.2 |
6/12 |
12 |
4-12 |
1242 |
|
GR2500 |
2695×1745×2130 |
2500 |
1200-1400 |
5.5 |
4 |
/ |
3-12 |
1598 |
||
GR3500 |
2750×1945×2300 |
3500 |
1600-1800 |
7.5 |
/ |
3-12 |
1794 |
|||
GRHT250 |
1560*980*1650 |
250 |
50-150 |
0.75 |
0.55 |
|
/ |
1.6-8 |
300 |
|
wooden case or suit for shipment
Excellent After-sale Service:
1. Technicians will be sent if necessary, to install and adjust the machine perfectly. Besides,
train your workers for the correct usage and daily maintenance.
2. Any spare parts you need will be sent to you directly from us.
3. Anything wrong with the machine, we will reply within 8 hours. Technicians will be sent
to your working site if you can not solve it under our guidance.
