FY300 Crawler Type Pneumatic Drilling Rig Crawler Drilling Rig Drilling Machine Water
US$ 1300 - 1500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia Master
Place of Origin:
China
Model Number:
FY300
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
3 days
Related Products
-
Huaxia Master FY400 New Design Water Well Drilling Rig Dth Drilling MachineUS$ 1300 - 1500MOQ: 1 Set -
FY600 Crawler Pneumatic Drilling Rig Crawler Drilling Rig Drilling Machine WaterUS$ 1300 - 1500MOQ: 1 Set
-
View Larger Image KQZ-200D 200 m Mini Trailer Down the Hole Drilling Rig Exploration Drilling Machine for Sale KQZ-200D 200 m Mini Trailer Down the Hole Drilling Rig Exploration Drilling Machine for Sale KQZ-200D 200 m Mini Trailer Down the Hole DrillingUS$ 1300 - 1500MOQ: 1 Set
-
HZ-130Y Hydraulic Rotary Drilling Rig Hydraulic Core Drill On SaleUS$ 1300 - 1500MOQ: 1 Set
-
XYX-130 Wheel Type Hydraulic Water Well Drilling Machine Rotary Drilling RigUS$ 1300 - 1500MOQ: 1 Set
Brand Name
Huaxia Master
Place of Origin
China
Model Number
FY300
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Weight
drilling rig
Dimension(L*W*H)
4350*1850*2750mm
Voltage
Diesel
Condition
New
Power(W)
85kw
CNC or Not
CNC
Drilling Speed
water well drilling rig
1. The applications of FY300 crawler pneumatic water well drilling rig
· civil engineering drilling
· geothermal drilling,
· drilling with large diameter and deep drilling footage
· It’s fast, flexible and efficient
2. The specifications of FY300 crawler pneumatic water well drilling rig
Model |
FY300 |
|
Gross weight |
t |
8.8 |
Dimension |
mm |
4350*1850*2750 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
300 |
Feed stroke |
mm |
6000 |
Travel speed |
km/h |
2 |
Grade ability |
max. |
30° |
Rising height from ground |
mm |
230 |
Wind pressure |
mpa |
1.7-3.3 |
Air consumption |
m³/min |
23 |
Engine power |
kw |
85 |
Rotary speed |
rpm |
55-115 |
Rotation torque |
n.m |
7200-8500 |
