Changsha Suny Electronic Technology Co.,Limited is a Professional manufacturer of the PCB production field. We have the factory in changsha of hunan, we can provide the:
1:PCB making machines
2:PCB etching machine
3:PCB through hole mahine
4:Completely PCB production line
5:Set up Small PCB factory
6:PCB prototyping laboratory
SUNY with more than 10 years experienced engineer team,we can povide the professional technical support as well as the overseas installation and training.
SUNY can provide all the related consumables and raw materials for the PCB machines and the PCB production line.
SUNY with the professional showing room in china, we provide the free installation and training service in china.
Item:Exposure machine,PCB exposure machine
Model:SUNY-ZBG300
Specification:
1. Usage: exposure processing of line, resistant welding and character ink graph in PCB production process
2. Structural features: large area effective exposure area, supporting more PCBs for exposure operation; advanced vacuum pump, making PCBs more close to the film; exposure machine with film contrapuntal light source, convenient for film aiming-hole operation
3. Function characteristics: PID intelligent control, the control system including tube delay protect function, maximum extending lamp life; with automatic exposure lamp warehouse door, starting lamp tubes and automatically opening warehouse door for exposure after strong stable light, exposure lamp warehouse door shutting down automatically when the exposure ends, ensuring accurate exposure and preventing ultraviolet radiation
4. Effective exposure area: 900mm×680mm
5. Exposure light: 3 KW advanced special exposure lamp
6. Effective wavelength: 420-640nm
7. Vacuum pump: vacuum degree 99.5%, power 200W
8. Exposure time: 0-999s can be set
9. Power supply: 220V/AC 50HZ 3.2KW
10. Overall dimension: length 1280mm×width 1100 mm×height 820mm
11. Weight: 130Kg.
