Coating Thickness Tester

GH-3  Coating Thickness Tester

Coating Thickness Tester

Function and usage

GH-3 Digital Thickness Tester is a high accuracy digital thickness tester which is gathered with optics, mechanology, electronics and algorithm, easy operation. digital showing the measurement results, reset setting convenience clear up measurement error. Mainly make the direct or comparing measurement for plastic film, paper and so on.

Features

General gauge stand adopts air damping device, the measurement is stable and reliable

With optical-mechanic-electric calculate, small volume, convenient use

With adjustable multifunctional measurement worktable

Equipped with RS232 communication interface and computer communication

Adopts measuring grating as long length, high accuracy, fast response

Specifications

1. measuring range :0.001~12.5 mm
2. Min. value:0.001mm
3. error:≤2%
4. Value variation :1μm
5. Measuring force:<1.5N
6. surface roughness of measuring head:Ra<0.2μm
7. Working temp.:0~40°C

Service:

1. One year coverage

2. Speedy reply, 12hrs response to customer questions

3. Software free update

4. Minor maintenance ---parts ship within 24 hrs

5. Major maintenance---Technical will be sent within 15 days

6. Free inhouse training for customer operator

                                                                                        About GBPI

GBPI is a professional manufacturer focused on developing

and producing packaging material test instruments. Founded in 2002, the company has received IOS9001 certification and reco gnized as high-tech enterprise and software enterprise by national authority. We hold numerous technology patents and software certificates from the national authority, and gained awards for technological progress.
