Description:
GOG600 Oval gear flow meter is a high-precision metering instrument used for continuous or intermittent measurement of liquid flow in the pipeline.
Product Detail:
Decomposition Diagram:
Product Show:
Features:
1.Measurement range widely,accuracy highly,reach 0.5%;
2.Simple structure, small pressure loss and strong viscosity
3.Measure high temperature and high viscosity liquid
4.Easy installation, horizontal or vertical installation
5.Liters, kilograms, cubic, gallons can be converted
Application:
GOG600 Oval gear flow meter widely used in oil, chemical, pharmaceutical, national defense, food and other industrial and commercial sectors of fuel flow detection.
Technical parameter:
Model |
GOG600-25 |
GOG600-40 |
GOG600-50 |
|
Medium |
Diesel, gasoline, oil, methanol |
|||
Connection |
thread,flange |
|||
Material |
Aluminum alloy |
|||
Diameter |
1 inch |
1.5 inch |
2 inch |
|
Flow range |
20~120L/min |
2~250L/min |
30~300L/min |
|
Unit price range |
0~99.99 |
|||
Amount |
0~999999.99 |
|||
Volume |
0~999999.99 |
|||
Accuracy |
±0.5% |
±0.5% |
±0.5% |
|
Repeatability |
±0.3% |
±0.3% |
±0.3% |
|
MAX viscosity |
1000CPS |
1000CPS |
1000CPS |
|
MAX working pressure |
1.8MPa |
1.8MPa |
1.8MPa |
|
