ERW 273 tube mill line:
ERW 273 high frequency welded pipe production line/pipe making machine/tube mill is designed to produce welded pipes diameter 114mm-273mm and pipe wall thickness 3.0-10.0mm ,as well as corresponding square and rectangle pipe
Product details:
Basic technical information of welded pipe production line
Product |
Round pipe |
114mm-273mm thickness: 3.0-10.0mm |
Square&rectangle tube |
90mm*90mm-210mm*210mm thickness: 3.0-8.0mm |
|
Length |
6-12m Length tolerance: ±3 |
|
Production speed |
20-45m/min |
|
Production capacity |
40,000 ton/year |
|
Powers |
Mill installed capacity |
350kw |
Line Area |
120m(length)*10.0m(width) |
|
Worker |
6-8 workers |
|
Raw material details |
Carbon steel coil |
GB/T 700:Q235B(ASTM:GR(σs 230)/JIS: SS400) |
Width |
357mm-860mm |
|
Coil ID |
600-800mm |
|
Coil OD |
Max 2000mm |
|
Coil weight |
15.0T |
ERW pipe making machine technique process:
Steel Coil--- Uncolier --- Shearing & Butt welder --- Storage/Accumulator --- Forming --- Welding --- Cooling--- Sizing--- Cutting saw--- Run out table ---Finishing---Pipe collecting and packing
ERW products list:
Model |
Round pipe (mm) |
Square pipe (mm) |
Thickness (mm) |
Working speed （m/min） |
|
HG20 |
φ8-φ20 |
6*6-15*15 |
0.3-1.5 |
120 |
Read more |
HG32 |
φ10-φ32 |
10*10-25*25 |
0.5-2.0 |
120 |
Read more |
HG50 |
φ20-φ50 |
15*15-40*40 |
0.8-3.0 |
120 |
Read more |
HG76 |
φ32-φ76 |
25*25-60*60 |
1.2-4.0 |
120 |
Read more |
HG89 |
φ42-φ89 |
35*35-70*70 |
1.5-4.5 |
110 |
Read more |
HG114 |
φ48-φ114 |
40*40-90*90 |
1.5-4.5 |
65 |
Read more |
HG140 |
φ60-φ140 |
50*50-110*110 |
2.0-5.0 |
60 |
Read more |
HG165 |
φ76-φ165 |
60*60-130*130 |
2.0-6.0 |
50 |
Read more |
HG219 |
φ89-φ219 |
70*70-170*170 |
2.0-8.0 |
50 |
Read more |
HG273 |
φ114-φ273 |
90*90-210*210 |
3.0-10.0 |
45 |
Read more |
HG325 |
φ140-φ325 |
110*110-250*250 |
4.0-12.7 |
40 |
Read more |
HG377 |
φ165-φ377 |
130*130-280*280 |
4.0-14.0 |
35 |
Read more |
HG406 |
φ219-φ406 |
170*170-330*330 |
6.0-16.0 |
30 |
Read more |
HG508 |
φ273-φ508 |
210*210-400*400 |
6.0-18.0 |
25 |
Read more |
HG660 |
φ325-φ660 |
250*250-500*500 |
6.0-20.0 |
20 |
Read more |
HG720 |
φ355-φ720 |
300*300-600*600 |
6.0-22.0 |
20 |
Read more |
The pipe machine’s main characteristics of the equipment:
1. In a very short period of time to finish the adjustment of the roller
2. Producing the different size of tubes,only need to change the rollers
3. Decreasing the number of workers, reduce the labor cost
4. Improve the service life of the equipment
5. The machine can be repaired alone
Company ability and product quality:
Our company has devoted technical team, most of the engineers are experienced experts in cold-formed machinery industry.My company manufacture policy ‘Quality must always come first’.
Based on the rich experience in the industry and the growing trade business, the company is expanding the scope of business and building a solid partnership in the fields of metallurgy ,fabrication and construction ,traffic engineer,mechanism and vehicle industry.Our business relationships mainly distribute in Southeast Asia, the Middle East ,Africa,Eastern Europe ,South America.
To learn more or discuss your project with our experts,welcome to contact us now
Our service:
1. Work out reasonable investment scheme,selecting rational model unit
2. Provide free equipment layout,factory planning for you
3. Provide free equipment foundation drawing,if necessary ,offer technical guidance on-site for equipment foundation construction
4. Provide equipment installation and commissioning, ensure the normal operation of production ASAP
Quality assurance:
We shall be responsible for quality problem resulted from design and manufacture with one year after successful installation and debugging and all the expenses for replacing parts and components(exclude human factors) shall be born by us
Debugging:
(1) Factory will send 1-2 technical engineers for installation and testing operation
(2) The site,the equipment foundation,cool constructions etc. Responsible by buyer according to equipment material which provided by supplier,the equipment for installation(lift equipment,tool etc.),the installation accessory material (wire,drive pipe,water pipe and so on),the labor force arranged by the buyer
(3) The buyer is responsible for power supply,water supply and gas supply to the equipment interface connector
(4) Buyer preparation notes:
(a) Machinery device takes the location(length*width)
(b) Power supply: Main power to equipment control bench,unit position
(c) Air feed: Air compressor(1.5 cubic meters/minutes)
(d) Water supply: water source to machine station
Company profile:
Botou Boheng Metallurgical Equipment Manufacturing Co.,Ltd was established in 2003, and located in Botou city Hebei province.Boheng is a high and new-technology enterprise specialized in design,development and manufacture of ERW welded pipe equipment,high precision slitting & crossing-cutting equipment,spiral welded pipe equipment,cold forming equipment and rollers.Boheng is the pioneer that had the key processing technology of the international advanced whole set welded pipe mill. Boheng always adhere to the enterprise policy “contribute to the society with excellent techniques, high quality products and perfect service”.
