Home > Manufacturing & Processing Machinery > Woodworking Machinery > Wood Saw Machine > PRECISION SLIDING TABLE PANEL SAW
PRECISION SLIDING TABLE PANEL SAW
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
UNITED ASIA
Place of Origin:
China
Model Number:
UA3200S
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
UNITED ASIA
Place of Origin
China
Model Number
UA3200S
Use
Woodworking
Certification
ISO9001
After-sales Service Provided
Overseas service center available
Warranty
one year
Weight
780KG
Dimension(L*W*H)
3200*2550*900mm
Condition
New
Type
Table Panel Saw
Style
Vertical
UA3200S PRECISION SLIDING TABLE PANEL SAW
TECHNICAL DATA
Dimension of sliding table |
3200*375mm |
Gross cut capacity |
3200mm |
Width of cut between saw blade and ripe fence |
1250mm |
Saw blade |
300mm (250-300) |
Height of cut 300mm |
70mm |
Speed of main saw blade |
6000r.p.m |
Tiling saw blade |
45 Degree |
Main motor |
5.5kw |
Scoring saw blade diameter |
120mm |
Speed of scoring saw blade diameter |
8000r/min |
Scoring motor |
1.1kw |
Net weight |
780kg |
Overall dimensions |
3200*2550*900mm |
Loading 20GP/40HQ |
10 SETS/22SETS |
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
1996
Overseas Office
Yes
Annual Export Value
Above US$100 Million
