Help CenterHigh Security Door Automatic Sliding Automation DSH-350
Related Products
-
Operating Room Automatic Hermetic Sliding Door For Hospital DoorUS$ 100 - 1000MOQ: 1 Set -
Automatic Telescopic Center Opening Sliding DoorUS$ 100 - 1000MOQ: 1 Set
-
Automatic Door PartsUS$ 10 - 500MOQ: 1 Set
-
Automatic Sliding Curve Door Operator System DCS-125US$ 100 - 1000MOQ: 1 Set
-
The Hot Sale Swing Automatic Door DSW-93NegotiableMOQ: 1 Piece
FUNCTION INTRODUCTION |
| 1. Intelligent control system, kinds of parameters can be adjusted manually or remotely. 2. Various functions can be set manually or remotely. 3. The main control unit has memory function of above setting no matter when power off or failed. 4. Low noise driven device is integrated with motor, turbine,worm and gear box. 5. Unique lock function, safe and reliable. 6. Advanced pushless motor has high efficiency, big torque and long working life. 7. Interlock function： one door fully closed, then another door can be open. 8. The backup battery is optional, power off or fire alarm, the door will be hold-open or hold-closed. 9. Five-range program setting 10. Closed force： Door is fully closed, it is tighten and difficult to open by force. 11. Installation is simple and convenient. |
TECHNICAL DATA |
|
Door configuration： single-leaf/ double-leaf Door leaf weight：1350kg 2x300kg Clean opening width：1000-2800mm,1800-3800mm Closed force： ＞100N Power voltage：AC220V±10%,50/60Hz Opening speed：100-230mm/s Closing speed：100-230mm/s Hold-on time：1-9s(adjustable) Manual push： Power consumption： Working environment temperature：-20℃-+50℃ |
