Technical Data
Model | YDL-2.0 | YDL-1.0 |
Power | Gasoline:20HP Diesel:25HP | Gasoline:13HP Diesel:9HP |
Walking speed | 0-8km/h | 0-5km/h |
Drive way | Full hydraulic transmission | Full hydraulic transmission |
Walking way | Bidirectional | Bidirectional |
Steel size | Φ560*900mm(front) Φ560*900mm(Rear) | Φ560*740mm(front) Φ560*800mm(Rear) |
Vibration force | 30KN | 25KN |
Vibration frequency | 65HZ | 70HZ |
Vibration clutch | Hydraulic vibration | Electromagnetic clutch |
Climbing Capacity | 30% | 30% |
Weight | 1900kg | 1100kg |
Packaging Details
WOODEN PACKAGE
Port
QINGDAO
Lead Time :
Quantity(Sets) 1 - 5 >5 Est. Time(day) 5 To be negotiated
Main Features
1, Honda gasoline engine or domestic well-known brand gasoline engine, diesel engine, brand name quality assurance, superior performance, easy to start
2, small radius of operation, can work in a narrow area.
3, the transmission mechanism adopts the domestic hydraulic transmission system, infinitely variable speed, easy to change direction and strong service life
4, Adopt well-known brand bearing and triangle belt to ensure machine quality.
5, diesel power electric start, gasoline engine manual start, light and flexible.
