ERW 50 tube mill line:
ERW 50 high frequency welded pipe production line/pipe making machine/tube mill is designed to produce welded pipes diameter 20mm-50mm and pipe wall thickness 0.8-3.0mm ,as well as corresponding square and rectangle pipe
Product details:
Basic technical information of welded pipe production line
Product |
Round pipe |
20mm-50mm thickness: 0.8-3.0mm |
Square&rectangle tube |
15mm*15mm-40mm*40mm thickness: 0.8-2.0mm |
|
Length |
6-12m Length tolerance: ±3 |
|
Production speed |
20-120m/min |
|
Production capacity |
15,000 ton/year |
|
Powers |
Mill installed capacity |
65kw |
Line Area |
50m(length)*4.0m(width) |
|
Worker |
6-8 workers |
|
Raw material details |
Carbon steel coil |
GB/T 700:Q235B(ASTM:GR(σs 230)/JIS: SS400) |
Width |
36mm-120mm |
|
Coil ID |
450-520mm |
|
Coil OD |
Max 1500mm |
|
Coil weight |
1.0-2.0T |
ERW steel tube field of use:
NO |
ERW tube applications |
1 |
Water pipe |
2 |
Heating pipe |
3 |
Low-pressure process pipeline |
4 |
Low-pressure fire fighting pipeline |
5 |
Sewage pipes |
6 |
Steel scaffolding pipe |
7 |
Wire and cable protection pipe |
8 |
Structural support steel pipe |
9 |
Industrial steel pipes |
10 |
Decoration pipe |
11 |
Oil & Gas pipes |
Company ability and product quality:
Our company has devoted technical team, most of the engineers are experienced experts in cold-formed machinery industry.My company manufacture policy ‘Quality must always come first’.
Based on the rich experience in the industry and the growing trade business, the company is expanding the scope of business and building a solid partnership in the fields of metallurgy ,fabrication and construction ,traffic engineer,mechanism and vehicle industry.Our business relationships mainly distribute in Southeast Asia, the Middle East ,Africa,Eastern Europe ,South America.
To learn more or discuss your project with our experts,welcome to contact us now
Welcome your inquiry!!!
Whatsapp/Wechat:+8617659717663
Email: anna@bhyjsb.com
