DJM Electrode sensor

This electrode sensor mainly used on boiler and to measure the boiler drum water level.

Specification:

1. Name: Electrode Sensor for Boiler Drum Level Measurement

2. Material: high quality alumina ceramics material.

3. Install method: Screw in

4. Bear Temperature : 300~600︒C

5. Insulating Resistance:≥500ΩM

6. Working Pressure:21-31Mpa

7. Working Time: 8000~10000 hours

8. Spare Parts: Porcelain Terminal and copper washer.
