Model Number |
OD11.5*ID6.5*L75mm-230V300W (Customizable) |
Product Name |
MCH ceramic heating tube igniter,Ceramic igniter for biofuel oventick |
Voltage |
110V-130V,220-240V (Customizable) |
Cold RW |
230V-300W (Customizable) |
Dimension(mm) |
OD11.5*ID6.5*L75mm (Customizable) |
Average life span |
Approx. 30,000 Hours |
Main materials |
96%Al2O3,Metal W,Ni,Ag |
|
Characteristics | fields of application
For more information, please contact me at: WeChat:1859192905 QQ:1169158556 E-mail: 1169158556@qq.com |
1. Small volume, high power density, thermal efficiency up to 98.6% 2. The power loss is small, the heat is fast, and there is no need to wait. 3. Widely used, acid and alkali resistant, corrosion resistant, dry burning, solid, gas, liquid. 4 .In line with EU RoHS (lead-free, cadmium, mercury, hexavalent chromium, PCBS and other hazardous substances) 5. The surface is not charged, safe and reliable. The MCH is widely used in all kinds of applications nowadays, such as: intelligent bidet seat, electric water heater, medical machine, dryer, electric heating splint, electric iron, vacuum flask, electric cooker, electric bonder, capper, UTR cylinder Condensation-proofer, IR physiotherapy equipment, intravenous injection heating, quick food heating, mini thermostatic bath for special crystal parts, automatic exhaust oxidation sensors, industrial equipment heater, and small heating appliance, etc. Ceramic igniter is not oxidized, not afraid of acid or alkali corrosion, all materials lead-free environmentally friendly non-toxic, ignition operation up to 100,000 times without damage. |
Provide your Installation space size, Working voltage, Rated power or Required temperature, we design and produce according to your needs.
We have many years of experience in ozone ceramic sheet ceramic plasma generating sheet ceramic igniter ceramic heating tube and ceramic heating sheet design production, as long as confirm that your needs do not exceed the limits of our existing equipment, can be produced.
1. About the product
All pictures are taken in kind, the appearance of the stock products is consistent with the pictures, and the peripheral accessories can be fine-tuned according to customer requirements.
2. About logistics
We will choose the safest and fastest delivery company.
3. About the sample
For samples under $1, 2 samples are available free of charge and the sample shipping costs are borne by the buyer.
4. About the delivery cycle
According to the product specifications and quantity, both parties negotiate.
To know more, please contact customer service.
For more information, please contact me at:
Yangling Zhibo Automation Technology Co., Ltd.
WeChat:13119138299
QQ:1169158556
E-mail:1169158556@qq.com
========================== Questions and Answers============
1. What is the operating voltage for a heater?
Approximately, square root of P*R, where P is the power you need and R is the resistance of the heater.
A heater only has a fixed resistance R at room temperature. Generally, there is no fixed operating voltage for a heater and it all depends on the heat transfer application (which determines the power P you need). Then roughly, the operating voltage V for your application would be the square root of P*R. The thing matters the most to a heater is the highest temperature it can endure. As long as the temperature at the hottest location (usually the geometry center of the internal winding coil in heater) is below that highest endurable temperature, it can output any power you need if you have a proper power supply and heat sink (thermal load). The above statement assumes a steady-state situation. For transient case (e.g. temperature rising process), large voltage jump should be avoided in case the large thermal shock or current shock. There are also other uncommon limits/properties which need to be considered in special situation. Please see physical properties next to the main product image.
2. How to determine the power I need to heat my objects to a certain temperature (e.g. 200 Celsius)?
Estimate the heat loss from your objects at a certain temperature (e.g. 200 Celsius) to environment or supporting frame through thermal radiation, conduction and convection. Please educate yourself by google if you are not familiar with these terms. You can definitely design your system to manipulate the three types of heat transfer to suit your need (e.g. reducing heat loss by using thermal insulation or thermal shield or polished surface, making temperature more uniform by using high thermal conductivity substrate). The power you need should be at least 30% over of your heat loss estimation for safety (1.3X).
