Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Processing Machinery Parts > XK7125 Milling Machine
XK7125 Milling Machine
US$ 10,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
haishu
Place of Origin:
Shandong, China
Model Number:
XH7132
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XH7125 High Speed Vertical CNC Machining CenterUS$ 27,000 - 30,000MOQ: 1 Set -
XH7132 VERTICAL MACHINE CENTERUS$ 12,000 - 20,000MOQ: 1 Set
-
XH7132 VERTICAL MACHINING CENTER / MACHINE CENTER CNC MACHINING WITH CEUS$ 20,000 - 25,000MOQ: 1 Set
-
XH7132 VERTICAL MACHINE CENTERUS$ 12,000 - 20,000MOQ: 1 Set
-
XH7146 New Cnc Vmc MachineUS$ 35,500 - 40,000MOQ: 1 Set
Brand Name
haishu
Place of Origin
Shandong, China
Model Number
XH7132
After-sales Service Provided
Overseas service center available
Condition
New
xk7125 milling machine
Machine use
This machine is applicable to vertical machining center for machining and mold making, can meet the processing requirements from roughing to finishing, to be completed by milling, drilling, tapping, boring and many other processes.
Main structural features of
1. fuselage and the main components are high strength cast iron, microstructure stability, to ensure the stability of long-term use of the machine;
2. bottom of column A-shaped bridge span structure, combined with the base of a large box, and significantly reduce the vibration of the body heavy cutting;
3. High-speed, high precision, high rigidity spindle unit;
4. Intermittent automatic lubrication;
5. Pneumatic loose, pull the knife system
This machine is applicable to vertical machining center for machining and mold making, can meet the processing requirements from roughing to finishing, to be completed by milling, drilling, tapping, boring and many other processes.
Main structural features of
1. fuselage and the main components are high strength cast iron, microstructure stability, to ensure the stability of long-term use of the machine;
2. bottom of column A-shaped bridge span structure, combined with the base of a large box, and significantly reduce the vibration of the body heavy cutting;
3. High-speed, high precision, high rigidity spindle unit;
4. Intermittent automatic lubrication;
5. Pneumatic loose, pull the knife system
Specification |
UNIT |
XK7124 |
Table size |
MM |
800*240 |
Spindle hole taper |
|
IS030 |
Travel range |
MM |
400*240*400 |
NO./width/distance of T-slot |
MM |
3-14-75 |
Max.load of table |
KG |
300 |
Distance from spindle nose to table surface |
MM |
60-460 |
Distance from spindle axis to vertical guideway |
MM |
300 |
Rapid feed speed |
M/MIN |
18 |
Feed speed |
MM/MIN |
2.5-3000 |
Spindle speed |
R/MIN |
40-6000 |
Spindle motor power |
KW |
3.7/2.2 |
Tool magazine capacity |
piece |
16 |
Max tool weight |
kg |
8 |
Max tool size |
mm |
Φ120*200 |
Positioning accuracy |
MM |
±0.015 |
Repeat position accuracy |
MM |
±0.0075 |
Overall dimension(L×W×H) |
MM |
1870×1520×2000 |
Net weight |
KG |
1500 |
Controller |
|
GSK25I |
