CNC250A CNC lathe with two spindles CNC turning milling composite machining center for hot sale
CNC250A Main technical parameters:
No. |
Item |
Unit |
parameter |
1 |
Bed maximum turning diameter |
mm |
250 |
2 |
Maximum turning length Z1 |
mm |
350/450/550 |
3 |
Maximum turning diameter |
mm |
160 |
4 |
Spindle nose type and code |
mm |
A6 |
5 |
Hydraulic chuck |
160/100mm |
|
6 |
Front spindle bore taper |
|
1:20 |
7 |
Spindle bore |
mm |
40 |
8 |
Maximum load-bearing chucked components |
kg |
100 |
10 |
2 - servo spindle motor speed |
mm/min |
0-8000 |
11 |
Rapid traverse X / Z |
mm/min |
40000 |
12 |
CS1; CS2 main servo motor power |
kW |
5.5 |
13 |
Turret power axis max speed rapidly |
rpm |
6000-12000 |
14 |
X1;servo motor maximum torque |
N.m |
10 |
15 |
Z1;Z2 servo motor maximum torque |
N.m |
15 |
16 |
Power Specifications |
v |
380±10%. 50Hz±1Hz |
17 |
Carrier transfer time (one station) |
s |
1.6(Horizontal 12) |
18 |
Carrier transfer repeat positioning accuracy |
mm |
0.005” |
19 |
X1 axis travel |
mm |
150 |
20 |
Z1-axis travel |
mm |
350/450/550 |
21 |
The Z2 axis Vice spindle travel |
mm |
650/750/850 |
22 |
Biaxial dynamic docking concentricity |
mm |
0.004 |
23 |
Hydraulic servo turret form |
|
Horizontal 12-station power |
24 |
Arbor size |
mm |
25*25 |
25 |
Machine weight |
kg |
3500 |
26 |
Outline dimension(L×W×G) |
mm |
2100×1350×1750 |
Standard configuration:
1.Taiwan 10TD control system
2.Hydraulic solid chuck 100
3.Cutting cooling system
4.X.Z axis linear guide P and ball mast C4
5.The spindle unit and motor
6.Horizontal 12 station servo turret
7.Bearing P4
8.Fully enclosed protection system
welcome to our company--------------Taian Haishu Machinery CO.,LTD IN China
