Alloy wheel Repair cnc Machine CK6187W
Alloy wheel Repair cnc Machine CK6187W Description
Alloy wheel Repair cnc Machine CK6180W, CK6187, CK6190 and CK6197W have the same technical parameters and configurations except the maximum wheel diameters. They are high precision, cost-effective and space-saving. These car CNC wheel lathes are your best choice for wheel machining, super-finishing and maintenance.
Alloy wheel Repair cnc Machine CK6187W Description
Alloy wheel Repair cnc Machine is composed of self-made mechanical parts such as the cast steel bed, spindle, fixing chuck and the feeding mechanism, the imported numerical control system,the automatic measuring system, the famous brand servo motors and the auxiliary parts like lubrication, light and cooling.
Main features of Alloy wheel Repair cnc Machine CK6187W
Automatic laser scanning and fast measurement.
Wheel data is acquired, processed and stored automatically .
Self-developed CNC software, automatically program optimization.
Precise and fast wheel processing.
Touch screen operation, support multiple languages
X / Z axis measurement, wheel surface and circumferential machining.
Three-color warning lights.
Automatic lubrication system.
Diamond cutting.
The machine can be customized according to customer requirements.
Alloy wheel Repair cnc Machine CK6187W specifications:
Item |
Unit |
CK6187W |
Max. wheel diameter |
inch |
31’’ |
Max. workpiece length |
mm |
750 |
Wheel measuring direction |
|
X,Z |
Measuring tool |
mm |
Laser, probe (optional) |
Measurement method |
|
Point measurement and quick scan |
Program optimization |
|
Manual and automatic |
Number of wheel processing programs |
|
100000 |
CNC System |
|
"HAISHU" special system (touch screen operation, 17 "screen LCD display). Universal CNC system (key operation, 10.4 "screen LCD display) (optional) |
Chuck |
|
Standard three-jaw,lengthened three-jaw (optional). With a quick chuck wrench |
Wheel processing |
|
Surface, Rim |
Mchining accuracy |
|
IT6~IT7 |
Surface roughness |
um |
Ra0.8~1.6 |
Main drive form |
|
Frequency control, servo drive (optional) |
Spindle speed |
rpm |
Factory setting 150~2000,>2000(optional) |
Main motor power |
kw |
7.5 |
Fast-moving feed |
mm/min |
X: 5000 Z: 8000 |
Repeat accuracy |
mm |
X: 0.01 Z: 0.015 |
Turret form |
|
Fixed turret,Electric turret (optional) |
Section of turning tool |
mm |
25×25 |
Machine size(L×W×H) |
mm |
2685×1750×1980 |
Net weight |
kg |
3300 |
standard exported wooden case
Taian Haishu Machinery Co., Ltd. is the professional CNC machine designer and manufacturer dedicated in supplying all kinds of cnc machine to worldwide customers. We had been always worked hard to become the leader in designing and manufacturing CNC lathes since the foundation in 2001. There are more than 60 talented experts and more than 12,000 square meters factory to guarantee the production and quality of CNC lathe machines. Our innovative, high-quality products include CNC lathe, wheel repair machine, cnc milling machine and other customized CNC machines. Product innovation, quality assurance and customer satisfaction are our long term commitment to our worldwide customers. Hope to build strong business relationships with you!
