Horizontal high precision metal cnc lathe machine CK6136A
Standard configuration:
1.CNC system: GSK928,
2.Manual chuck ,
3.Manual tailstock,
4.Vertical four-station electric turret,
5.Automatic lubrication system,
6.Turning the cooling system.
Select configure
1.CNC system: GSK980, KND, Siemens, Fanuc, etc.,
2.Hydraulic chuck (solid and hollow), pneumatic chuck,
3.Hydraulic tailstock, pneumatic tailstock,
4.Automatic feeder,
5.Horizontal six-station turret, eight-station turret, tool row.
Item |
Unit
|
CK6136A |
Max. rotation diameter over bed |
mm |
φ360 |
Max. rotation diameter over pallet |
mm |
φ245 |
Max. workpiece length |
mm
|
750/1000 |
|
Main transmission form
|
|
Independent spindle |
Spindle speed mode |
|
Frequency stepless speed |
Spindle speed range |
r/min |
200~2500 |
Spindle head form |
|
6-A2 |
Spindle bore |
mm |
φ60 |
Spindle hole outside taper |
|
MT6 |
Chuck diameter |
mm
|
φ200 |
|
Main motor power |
kw
|
5.5 |
Turret maximum stroke |
mm
|
X:260 Z:760/1020 |
|
Fast-moving feed |
mm/min
|
X:6000 Z:8000 |
Repeat positioning accuracy |
mm |
X:0.01 Z:0.015 |
Workpiece accuracy |
|
IT6-IT7 |
|
Workpiece surface roughness |
|
Ra1.6 |
Dia. of tailstock quill |
mm
|
φ60 |
|
Tailstock quill stroke |
mm
|
120 |
Taper of tailstock quill |
|
MT4 |
Repeat positioning accuracy |
mm |
0.008 |
Section of turning tool |
mm
|
20×20 |
Size(L×W×H) |
mm |
2170/2420×1540×1650 |
Net weight |
kg
|
1800/2000 |
Horizontal high precision metal cnc lathe machine CK6136A with standard export package
GUARANTEE AND AFTER-SALE SERVICES:
1.one year guarantee for whole machine
2.24-hours technical support by E-mail or telephone
3.User-friendly English software or Russian or Spanish, Users manuals and Detailed Videos/CD
4.Provide extra accessories for the machine
5.Also provide service of make program according to your drawings
6.Customized or special design is OK.
