Full automatic small cnc lathe machine CK0660A with robot feeder
.Main technical parameters
Item | Unit | Technical parameters |
Max. rotation diameter over bed | mm | Φ300 |
Max. rotation diameter over pallet | mm | Φ150 |
Max. workpiece length | mm | 120 |
Pneumatic chuck diameter | mm | 160 |
Spindle hole diameter | mm | Φ70 |
Pull tube hole diameter | mm | Φ60 |
Robot max. crawling diameter | mm | Φ56 |
X / Z axis repeat positioning accuracy | mm | 0.012/0.013 |
X-axis stroke | mm | 350 |
Z-axis stroke | mm | 240 |
X-axis fast-moving speed | m/min | 10 |
Z-axis fast-moving speed | m/min | 10 |
Spindle speed | r/min | 150-2200 |
Turret form |
| Row |
Main motor power | kw | 3 |
Machine dimensions((L×W×H)) | mm | 1860*1100*1580 |
Net weight | kg | 1200 |
Main features
1.1 The machine is special CNC lathe designed and manufactured by HAISHU company according to customer's requirements.
1.2 Robot feed, pneumatic clamping, automatically receive material , part processing is fully automated.
1.3 The processing range of the machine tool is extensive, high efficiency, simple operation.
1.4 The machine can meet one-time processing of the outer circle, hole, thread, end face, grooving, cone, spherical and other processes of the lot size parts.
Main configuration
3.1 GSK980 system
3.2 Pneumatic chuck, manipulator, pusher, receiver.
3.3 X / Z axis linear guide
3.4 Row knife
3.5 Stainless steel internal protection
3.6 Automatic lubrication system
3.7 Cooling system
GUARANTEE AND AFTER-SALE SERVICES:
1.one year guarantee for whole machine
2.24-hours technical support by E-mail or telephone
3.User-friendly English software or Russian or Spanish, Users manuals and Detailed Videos/CD
4.Provide extra accessories for the machine
5.Also provide service of make program according to your drawings
6.Customized or special design is OK.
standard exported wooden case
Taian Haishu Machinery co.,Ltd. is specialized in design production and sales of CNC machine tools. The leading product is "HAISHU" brand CNC lathe,CNC Turning center, Machining center, etc..
Our company is equipped with the ministry of domestic trade and foreign trade, with independent import and export right. Product best-selling more than 20 domestic provinces and municipalities and autonomous regions, and exported to the US, Britain, Germany, Italy, Turkey, Greece, Sweden, Bulgaria, Romania, Denmark, Lebanon, Czechoslovakia, New Zealand, Australia, Peru, Ecuador, Colombia, Chile, Argentina, Russia, Belarus, Lithuania, Serbia, Tunisia, Bahrain, South Africa, South Korea, India, Indonesia, Malaysia, Thailand, the Philippines, Egypt, Iran, Bangladesh, Iraq, Yemen, Mongolia,etc. more than 45 countries.
We have years of CNC machine tool development and manufacturing experience, in order to "science and technology innovation, good faith service" business philosophy in close cooperation with old and new customers, grow together, common development.
