Hydraulic Surface Grinding Machine MY1230AHD
US$ 5,000 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
WMT
Place of Origin:
Anhui, China
Model Number:
MY1224
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
M1308 M1408 Cheap Mini Grinder Universal Cylindrical Grinding MachineUS$ 4,450 - 6,000MOQ: 1 Set -
M1320HX500,800mm Cheap Price for Universal Cylindrical Grinding MachineUS$ 8,000 - 12,000MOQ: 1 Set
-
M1420H/Fx500,M1420H/Fx800 Cylindrical Grinding Machine Type and New Condition Universal Cylindrical GrinderUS$ 5,000 - 10,000MOQ: 1 Set
-
New Arrival M1332B MC1332B Cheap Grinder Universal Cylindrical Grinding MachineUS$ 5,000 - 10,000MOQ: 1 Set
-
M1432B Cylindrical Grinding Machine Type and New Condition Universal Cylindrical GrinderUS$ 5,000 - 10,000MOQ: 1 Set
Brand Name
WMT
Place of Origin
Anhui, China
Model Number
MY1224
Type
Surface Grinding Machine
Certification
CE certificate
After-sales Service Provided
Engineers available to service machinery overseas
Weight
1650kgs
Dimension(L*W*H)
1960x1630x1870mm
Voltage
customer appoint
Condition
New
Power(W)
1.5kw
CNC or Not
Normal
Product Description
Features:
Hydraulic surface grinding machine with electric magnetic chuck MY1230
| Technical Parameters | Unit | M1230AHD | |
| piece to be Ground ( L×W×H) | mm | 700×320×350 | |
| Max. Grinding Length | mm | 660 | |
| Max. Grinding Width | mm | 370 | |
| Distance From Table Surface To Spindle Center | mm | 490 | |
| Slide way | Double V rail | ||
| Maximum work load | Kg | 200 | |
| Table Size (L×W) | mm | 600×300 | |
| Number of T -Slot | mm×n | 14×1 | |
| Speed OF Working Table | m/min | 18 | |
| Cross Feed On Handwheel | mm | 0.02/Graduation2.5/revolution | |
| Vertical Feed On Handwheel | mm | 0.01/Graduation1.25/revolution | |
| Wheel Size (dia.×width×bore ) | mm | 200×20×31.75 | |
| Spindle Speeds | 50Hz | rpm | 2850 |
| Spindle Motor | Kw | 3.04 | |
| Hydraulic station motor | Kw | 2.0 | |
| The machined surface of the base of parallelism | mm | 0.003 | |
| Surface Roughness | μm | Ra0.32 | |
| Working Pressure | Mpa | 3 | |
| Max.Capacity | L/min | 18 | |
| Minimum Of Numerical | L | 80 | |
| Coolant Pump | Kw | 0.5 | |
| Machine Size (L×W×H) | mm | 2100×1540×1760 | |
| Packing Size (L×W×H) | mm | 2150×1600×1800 | |
| Cross,Net | T | 2.2,2.36 | |
Workshop Show:
