Surface Grinding Machine M7140
US$ 11100.00 - 11200.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
WMT
Place of Origin:
Anhui, China
Type:
Surface Grinding Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Universal Cutter Tool Grinder MQ6025AUS$ 8,000 - 9,000MOQ: 1 Set -
M20A Mini Size Grinding Machine Precision Universal Tool Grinder Small Polishing MachineUS$ 265 - 365MOQ: 1 Set
-
Tool Grinder M30A U2 Type Universal Cutter Grinder in Stock Polishing MachineUS$ 265 - 365MOQ: 1 Set
-
BG-150 150mm Large Face Belt Grinding Machine for Wood and Metal WorkingUS$ 985 - 1,020MOQ: 1 Set
-
BG75 Portable Large Grinding Machine Sale Polishing Machine Belt GrinderUS$ 985 - 1,020MOQ: 1 Set
Brand Name
WMT
Place of Origin
Anhui, China
Type
Surface Grinding Machine
Certification
CE certificate
After-sales Service Provided
Engineers available to service machinery overseas
Weight
3300kgs
Dimension(L*W*H)
2400x1990x2180
Voltage
customer appoint
Condition
New
Power(W)
5.5kw
CNC or Not
Normal
Max. Grinding Length
800mm
Features:
1.Compact structure and easy operate
2.Hydraulic transmission on longitudinal manual and auto feed to transverse,rapid movment and micro adjust mechanism on vertical.
| Specification | M7140 | |
| Max workpiece to be ground | 1000x400mm | |
| Maximum table vertical movment | 1100mm | |
| Distance from table to spindle center | 570mm | |
| The maximun lateral displacement of the grinding head | 450mm | |
| Vertical head feed handwheel graduation value/ each grid | 0.01mm | |
| Vertical head feed handwheel graduation value/each rotates | 1mm | |
| Fast lifting motor | Power | 0.37KW |
| Speed | 1440rpm/min | |
| Wheel Size(dia×width×bore) | φ350x40x127mm | |
| Spindle speed | 1440rpm/min | |
| The total power of electeic motor | 11KW | |
| Spindle motor | 7.5KW | |
| The oil pump motor | 3KW | |
| The mechanical surface of the base of parallelis | 300/0.004mm | |
| Surface roughness | Ra:0.63μm | |
| Gross/Net weight | 4000/4600kgs | |
| Packing size | 2800x1750x2350mm | |
Details about surface grinding machine M7140:
