Help CenterCS315 CS350 Precision Circular Saw Metal Sawing Machine
Related Products
-
GW4028(S280A) Cheap Metal Cutting Band Saw MachineUS$ 2,100 - 8,000MOQ: 1 Set -
GW4038(S380) Band Saw Machine Price With CEUS$ 2,000 - 3,000MOQ: 1 Set
-
GW4230/50(H-300HA) Double Column Horizontal Band Sawing Machine for Metal CuttingUS$ 3,500 - 4,000MOQ: 1 Set
-
GH4240 Cheap Sawing Machine Metal Band Saw Machine Price With CEUS$ 4,500 - 6,800MOQ: 1 Set
-
GW4250/70(H-500HA/1) Semi Auto Cutting Precision Band Saw Machine for Metal CuttingUS$ 3,500 - 5,000MOQ: 1 Set
Circular saw features:
Vice complete with anti-burr device
Movable head 45° right and left
Reduction unit in oil bath
Membrane pump for coolant
Our circular saw features a double speed motor and with low noise can slow down through worm and gear.
The HSS saw blade of our circular saw is highly efficient and durable.
The 24V low-voltage controlled hand switch is convenient for operation
The safety hood of saw blade opens or closes according to the cutting needs, making it safety.
The cooling system of circular saw can prolong the service life of saw blade and improve the precision of the workpiece.
Item No. |
388019 |
388020 |
|
Model |
CS-315 |
CS-350 |
|
Max. blade size |
315mm |
350mm |
|
Capacity |
Circular @90° |
100mm(4’’) |
120mm(4.7’’) |
Rectangular @90° |
140x90mm(5.5”x3.5”) |
140x100mm(5.5”x4”) |
|
Circular @45° |
90mm(3.5”) |
105mm(4.1”) |
|
Rectangular @45° |
100x0mm(4”x3.5”) |
100x100mm(4”x4”) |
|
Blade speed @50HZ |
18,36rpm |
18,36rpm |
|
Vice opening |
145mm(5.7”) |
145mm(5.7”) |
|
Motor power |
750W 1HP/1.3kW 1.7HP(3PH) 1.1KW 1.5HP(1PH) |
||
Drive |
Gear |
Gear |
|
Packing size |
98x62x90cm(body) 77x58x47cm(stand) |
98x62x95cm(body) 77x58x47cm(stand) |
|
N.W/G.W |
185/207kg |
190/212kg |
|
Send Inquiry to This Supplier
