Factory Direct Sale ZQ3035x10 Manual Type Wide Use Radial Drilling Machine
US$ 1,500 - 2,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
WMT
Place of Origin:
Anhui, China
Model Number:
ZQ3035x10
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZQ3040 Small Mechanical Radial Drilling MachineUS$ 1,500 - 2,000MOQ: 1 Set -
ZQ3040 Mechanical Radial Drilling Machine for Metal DrillUS$ 1,500 - 2,000MOQ: 1 Set
-
Z5032C Z5040C Z5045C Metal Hole Vertical Drilling MachineUS$ 1,180 - 1,280MOQ: 1 Set
-
Vertical Drilling Machine Model Z5045 With CE StandardUS$ 1,180 - 1,300MOQ: 1 Set
-
Factory Direct Sale ZQ3050x16 Manual Type Radial Drilling Machine With CertificateUS$ 1,500 - 2,000MOQ: 1 Set
Brand Name
WMT
Place of Origin
Anhui, China
Model Number
ZQ3035x10
Certification
CE ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Weight
800kg-1100kg
Dimension(L*W*H)
1500x705x2100mm
Voltage
customer appoint
Condition
New
Power(W)
2.2kw
CNC or Not
Normal
Drilling Speed
1200rpm
Features:
1.Radial drilling machine
2.Transmission:Mechanical transmission
3.Max. drilling diameter:35mm
4.Spindle taper:Morse 4
5.Spindle travel:200mm
Specification:
Technical parameters |
ZQ3035×10 |
Max Drilling Diameter(mm) |
steel 32 /iron 35 |
Spindle center to column (mm) |
360-900 |
spindle box travel (mm) |
550 |
Spindle nose to table (mm) |
260--1000 |
Spindle travel (mm) |
200 |
Spindle taper(Morse) |
4 |
Spindle speed range (r/min) |
75/130/240/380/660/1200 |
Spindle speeds series(mm/r) |
0.10/0.16/0.25 |
Radial rotation Angle |
360° |
Main motor power( kw) |
2.2 |
Lifting Motor Power ( kw) |
0.75 |
Machine weight (kgs) |
1100 |
Machine overall size (L*W*H mm) |
1550×720×2050 |
