CK0640 cnc lathes chinese turning with bar feeder mini machine
| SPECIFICATION | ||
| Items | CK0640 | |
| Spindle bore | Φ42mm | |
| Max. swing over bed | Φ300mm | |
| Max. swing over carriage | φ130mm | |
| Max length of work piece | 240mm | |
| X- axis max motion traveling schedule | 200mm | |
| X-axis fast moving speed | 6000mm/min | |
| Z- axis fast moving speed | 8000 mm/min | |
| X-axis feed rates | 1~2000mm/min | |
| Z- axis feed rates | 1~1800mm/min | |
| Range of spindle speed | 50~2500rpm | |
| Thread machining scope (metric system) | 0.25~12mm | |
| Thread machining scope (British system) | 28~3 1/2 | |
| Stations of tool carrier | gang-type tool carrier | |
| Power of the main drive motor | 3KW | |
| Overall dimensions(L×W×H) | 1550×920×1450 | |
| Net weight | 850 kg | |
CK0640 cnc lathes chinese turning with bar feeder mini machine using the GSK controller system to realize the Two - axis Control .The use of FANUC, Siemens, KND and other systems; with less noise, high precision, excellent performance characteristics, the CNC machine tools using mechanical and electrical integration design. Beautiful appearance, reasonable structure, wide range of uses, easy to operate. The machine can be automatically controlled, can automatically process a variety of parts of the first round, end, slot, any cone, spherical, and a variety of British and English cylindrical, tapered thread
CK0640 cnc lathes chinese turning with bar feeder mini machine
1. Improve efficiency. The speed of the clamping of the workpiece through the spring collet is one third more than the manual chuck, even much faster than the hydraulic chuck. A skilled worker can operate 2-3 machines at the same time.
2. Configured the automatic feeding device, can ensure that the workpiece does not bend deformation in the machine under the rapid operation.Applicable to batch processing of the workpiece that diameter from 5mm to 42mm, length within 3m.
3.More accurate and efficiently,the bed rails work more efficiently than engine lathe , the ball screw is more accurate,too.
4.Use for long time,ultra-audio quenching, The lathe bed and guide through the ultra-audio quenching, it could work more than 2 or 3 years of time than before.
5.Good protection,totally closed protection, better protection for rails, ball screws and bearings.
6.Good lubrication, it use of centralized lubricating oil, effective lubrication of each parts, increase the life of the lathe for at least 3 years.
The main product of Taian Luyoung Machinery Co.,Ltd is CNC lathe machine, CNC milling machine, CNC machine centers,CNC swiss type automatic lathe. Annual output is 900sets/ year.
1.More than 20 years of production experience.
2.Exported more than 40 countries.
3.More than 300 staffs in factory.
4.CE and ISO9001 certification .
5.7×24 hours online service.
Why choose our ck0640 cnc lathe ?
1. Factory price.Spend the least money on the best machines.
2.Low failure rate.All the accessories use the famous brands at home and abroad;More than 20 years' experience in this field,strictly control the quality.
3. Supprt oversea service.Our engineer have more exprience for oversea service,supply good service.
4.Export more than 40 countries and receive good feedback from our customer.
5.Trade Assurance.All of the order could placed by Trade Assurance, keep your money safe.
1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of collision and keep the goods intact.
Exhibition
1. Our customers come from more than 40 different countries and promote the most suitable products for different countries to provide the best service;
2 we participated in many exhibitions, the Chinese machinery exhibition, guangzhou commodities fair, through the exhibition to expand overseas market, we invite customers to visit our factory, also can be customized according to customer demand, through our products and services for customers
1. Warranty for one year .
2.Supply 7×24 hours online technology support.
3.Professional solution one by one.
4.Free training for customers online or in our factory.
5.The oversea service is available.
How long is your warranty period?
A: our warranty period is one year, and we will maintain the product free of charge during the warranty period.Use our machines to supply standard parts and accessories during shipment.In the correct operation, if there are any damaged parts or accessories, we will replace them immediately by airmail or express mail.
What kind of packing do you have?
Answer: we use a plywood cases, to ensure the packing quality durable, fully protect the safety of the goods in the cabinet, appearance is bright and clean, smooth and beautiful, durable, has low cost, big load, afraid of sun rain no moth, etc.
How long will your delivery date be?
A: our delivery date is one month.30 days
CK0640 cnc lathes chinese turning with bar feeder mini machine products can be customized?
A: of course, if our product can't meet your need, tell us the model and send us the drawing, recommend suitable products to you, we can also design and produce the machine meet your requirements.
How can I contact you?
Through cell phone number and QQ, there is also email contact.
