CK6130 small metal lathe machine cheap cnc
| CK6130 small metal lathe machine cheap cnc | |
| Item | CK6130 |
| Max. swing dia. over bed | 320mm |
| Max. swing dia. over cross slide | 100mm |
| Max. processing length | 400mm(collet) |
| Dia. of spindle hole | 48mm |
| Through hole dia. of drawing pipe | 41mm |
| Spindle speed | 50-3000rpm |
| Tool holder | gang type tool holder |
| Tool bar section | 20x20 16X16mm |
| Main motor power | 4kw |
| X/Z axis travel stoke(mm) | 300/380 |
| X/Z axis fast feeding speed | 8/10 m/min |
| X/Z axis position accuracy(mm) | 0.01/0.015 |
| X/Z-axis repeatability(mm) | 0.012/0.013 |
| Clamping | Pnematic collet |
| Tailstock sleeve dia. | 60mm |
| Tailstock sleeve travel | 100mm |
| Tailstock taper | MT4 |
| Dimension | 1750X1200X1570 |
| weight | 1220kg |
The CK6130 small metal lathe machine cheap cnc machine uses the design of mechanical and electrical integration, generous appearance beautiful, reasonable structure, easy operation. The machine adopts the integral bed foot, the stability is better. Wear-resistant cast iron after ultra-audio quenching treatment, to ensure the accuracy of the equipment and stability. The fully enclosed cover ensures that a drop of water does not leak out of the machine.
1.CK6130 small metal lathe machine cheap cnc Processing complex and high precision workpiece. Bed head box optimization design, suitable for discs, shaft parts of the turning process, you can line, arc, metric thread, long thread processing, can be applied to the complex shape of the complex and high precision disk type, shaft parts Processing.
2.CK6130 High hardness, good rigidity, high audio quenching, machine guide rails and saddle rails are using special materials, hard rail, high frequency quenching, super hard wear and tear, durable, good processing accuracy
3.Automatic lubrication, the lubrication point of the use of forced automatic lubrication device for quantitative quantitative lubrication of the screw and guide rail, when there is an abnormal state or lack of fuel, the automatic warning signal.
4. cnc lathe machine High precision, low noise. Spindle high precision double ball bearing support, low noise, high precision, good stability
5.Tailstock self-protection function, tailstock with fast cam clamping device, high efficiency. Tailstock sleeve to prevent the drill bit rotation device, to avoid the malfunction caused by the drill bit rotation and damage the tailstock sleeve hole taper, the effective protection of the tailstock parts.
6.Easy to operate, especially for complex parts or high-precision high-volume parts of the processing, but also the first choice of numerical control teaching.
1.Port: Qingdao port or Shanghai port
2.Payment method: T/T, L/C, D/P, D/D etc.
3.Payment: 30% T/T as deposit, 70% balance shall be paid before shipment.
4.Delivery time: 30 days after receive the 30%T/T deposit.
Luyang CNC machinery company has 20 years of production lathe experience, main CNC lathe, CNC milling machine, processing center, Swiss CNC lathe high-tech enterprise.The company has a professional production and development team and favorable after-sales technical team support.The company takes the strength to make the product, the service wins the customer, the customer as the basic management concept.Our company has gained a good reputation both at home and abroad by providing customers with cost-effective CNC machine tools and excellent timely sales advice and after-sales service.Development, innovation, people-oriented, is the direction my company has been working on.
Our company continuously strengthen product performance improvements, innovation cost-effective CNC machinery, optimize product quality control system, to provide global support services as the dominant direction of the development of the company.
1. Our customers come from more than 40 different countries and promote the most suitable products for different countries to provide the best service;
2 we participated in many exhibitions, the Chinese machinery exhibition, guangzhou commodities fair, through the exhibition to expand overseas market, we invite customers to visit our factory, also can be customized according to customer demand, through our products and services for customers
1.Non-fumigation packaging, we use seaworthy plywood.
2. Steel base plate, it is stronger 3-5 times than normal plywood base plate.
3.Water-proof and damp proof, water resistant film wraped all the machine.
4.Fully sheathed case,prevention of collision and keep the goods intact.
1.Our company has 20 years of experience in CNC lathes.Our company produces more than 1000 CNC machine tools per year, more than 40 countries export, and get good evaluation and affirmation.The high quality assurance of our lathe has good rigidity and stability.
2.electrical components from famous brand, provided by the Japanese and Taiwanese brands, its mechanical precision reach or exceed the international standard. Our CNC lathe is durable, safe and reliable, life for more than 10 years.
3. After 20 years of improvement, we have formed a complete production to maintain high quality and control costs. We will provide high quality prices to help you establish advantages in your local market.
4.We have a professional technical service team that provides the best service for you. Overseas services can provide 24-hour online sales and free after-sales service.
