CK6130 Used CNC metal spinning lathe machine for sale
CK6130 Used CNC metal spinning lathe machine for sale havefine appearance . With advantage of high speed ,high precision ,efficient ,It’s suitable for large-volume ,medium and small batch production of various kinds of complex parts .
CK6130 Used CNC metal spinning lathe machine for sale
| Item | CK6130 |
| Max. swing dia. over bed | 320mm |
| Max. swing dia. over cross slide | 100mm |
| Max. processing length | 400mm(collet) |
| Dia. of spindle hole | 48mm |
| Through hole dia. of drawing pipe | 41mm |
| Spindle speed | 50-3000rpm |
| Tool holder | 4-station tool holder |
| Tool bar section | 20x20 16X16mm |
| Main motor power | 4kw |
| X/Z axis travel stoke(mm) | 300/380 |
| X/Z axis fast feeding speed | 8/10 m/min |
| X/Z axis position accuracy(mm) | 0.01/0.015 |
| X/Z-axis repeatability(mm) | 0.012/0.013 |
| Clamping | Pnematic collet |
| Tailstock sleeve dia. | 60mm |
| Tailstock sleeve travel | 100mm |
| Tailstock taper | MT4 |
| Dimension | 1750X1200X1570 |
| weight | 1220kg |
| Standard configuration: | Option configuration: |
| GSK 928TD-L | Siemens,fanuc cnc controller |
| Pneumatic spring collet(2pcs free) | 4 station electrice tool holder |
| Gang type tool carrier | Auto feeder system |
| Manual Tailstock | Pneumatic chuck |
| Auto lubrication system | Hydrualic chuck |
| Lighting system | pneumatice tailstock |
| Cooling system | hydraulic tailstock |
|
380V 3 phase(if your local have special request pls let us know) |
1.four or six-station knife tool optional
3.Automatic lubrication system minimize the damage on the machine ,extend the service life
3.Superaudio quenching guide rail with excellent wear resistance and durable service life , High rigidity single spindle casting ,frequency conversion motor and constant speed moving
4.High rigidity single spindle casting with hardness over HRC 50°.
5.removable lathe shield , secure user’s safe and operation convenience .
· Packaging:sea worthy standard wooden case
· Shipment: within 15 days after payment
Taian Luyoung Machinery is located in Shandong province , which is the region of world famous mountain Tai and one of the cradleland of Chinese culture . Luyoung have engaged in the line of manufacturing and trading CNC machines for more than 20 years.Our prodct contains:CNC lathe machine , CNC milling machine,CNC machine center , CNC Swiss type lathe . With mission “ credit is the basic , quality is the first ” , we can ensure the prime quality and the most impressive price in the industry, we are going further and further on pursuing high standard high quality products and high satisfaction .
1. Customized service:Just tell us your needs about our service or the goods.
2. 7*24hours service:We’d love to offer help anytime,be free to contact us please.
3. Customer visiting & Free training :Welcome to China and visit our workshop and products
4. After sales service: We supply replacement parts for free if the machine is proved defective within 12 months .While the guarantee period of computer range from 1-3years.according the brand.
- What if I have problem with using mahine ?
(1)every machine would be equiped with a manual operation
(2)Free training is available .
(3)Be free to call or E-mail us anytime ,we're ready to offer help in 7*24 hours .
- I don't know how to choose the right model?
Send us the workpiece ,we'll help you to choose the right one.
- About payment .
We accept L/C,T/T,D/A,D/P ,and 30% deposit advanced by T/T ,the balance should be paid before the shipment.
- About delivery .
Generally,we can deliver the goods within 30 days .
- How can I get the quotation ?
You can contact us by phone or e-mail .Send us your requirments ,the best offer would be provided soon.
