4 axis cnc lathe machine with linear guidway and hydraulic chuck or collet
This is Special model ,We supply one by one solution,pls kindly directly to get your own solution
Let’s talk more online!
Specification :
TNC-350L |
Item |
Unit |
Specification |
|
|
Capacity
|
Max Turning Dia. |
mm |
Φ350 |
|
Max Cutting Dia. |
mm |
Φ300 |
||
Swing over on the bed |
mm |
Φ120 |
||
Max Machining length |
mm |
350 |
||
Spindle nose |
GB |
A2-5 |
||
Chuck |
|
Hydraulic chuck 6”(3JAW +4JAW) |
||
Spindle Unite |
Φ56 |
RMP |
3500 rpm/min |
|
Bar thru the hole |
mm |
Φ44 |
||
Feed XZ |
Screw |
|
mm |
|
Taiwan |
mm |
X2508 Z3210 |
||
XZ axis Travel |
mm |
X 350 |
||
mm |
Z 350 |
|||
Linear |
Taiwan |
mm |
X 30 Z35 |
|
Accuracy |
positionaI accuracy |
|
0.01 |
|
Repositioning Accuracy |
|
0.003 |
||
Tail Stock |
sleeve travel |
mm |
100 |
|
Tailstock taper |
|
MT4 |
||
Tool Holder |
|
|
|
|
6 station electric tool holder |
set |
Tool size:20X20 |
||
|
dimensions (length x width x height) |
|
1980X1550X1750mm |
|
Weight |
|
1960kg |
||
Standard configuration:
ü GSK 980D-L
ü High speed linear guidway
ü Manual 3 jaw chuck
ü 4 station tools carrier
ü Auto lubrication system
ü Lighting system
ü Cooling system
ü 380V 3 phase(if your local have special request pls let us know)
Option configuration For TNC-350L
:
ü 6 /8 station electrice tool holder
ü Auto feeder system
ü Pneumatic chuck
ü Hydrualic chuck
ü Chip conveyor
| |
| |
|
Production Capatity: CNC Lathe Machine:400 sets/year CNC Milling Machine:300 sets/year Other CNC Machine 200sets/year | |
| |
| Workshop Detail: | |
| |
|
About factroy Established in 1995, covers an area of 35,000 square meters,and more than 300 workers in all. |
| Our Customer |
|
|
| Trade Contact! |
|
You Will Get Best Offer Within 24 Hours Attn : Bruce Yang Mobile &WhatsApp &Wechat : +86-18660852746 Skype :bruceyang688 |
|
