US$ 9,000 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Lu Young
Place of Origin:
Shandong, China
Model Number:
TNC-350L
Contact Supplier Request Quote Chat Now
5 Axis Machining Center Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Lu Young
Place of Origin Shandong, China
Model Number TNC-350L
After-sales Service Provided Engineers available to service machinery overseas
Condition New

High speed and economic 3 Axis 4 Axis CNC Lathe Machine with c axis and y axis milling and drilling function TNC-350L

This is Special model ,We supply one by one solution,pls kindly directly to get your own solution

Chat with US

Let’s talk more online!

High speed 3 Axis CNC Lathe Machine with c axis and y axis milling and drilling function




Product Description







High speed 3 Axis CNC Lathe Machine with c axis and y axis milling and drilling function

Our advantage:

  • 20 years experiences in cnc lathe machine reserach and production.
  • Mechanical precision of our cnc lathe machine  meet or exceed international standards
  • High reliability ,long lifetime to 10 years
  • Friendly factory price
  • One year warranty for whole machine,GSK CNC System is 3 years
  • Professional engineer team to help you choose the suitable model and configuration.
  • 7X24 hours telephone or online technology support for free.

Specification :



TNC-350L

Item

Unit

Specification

Capacity



Max Turning Dia.

mm

Φ350

Max Cutting Dia.

mm

Φ300

Swing over on the bed

mm

            Φ120

Max Machining length

mm

350

Spindle nose

GB

A2-5

Chuck



  Hydraulic chuck 6”(3JAW +4JAW)

Spindle Unite

Φ56

RMP

3500 rpm/min

Bar thru the hole

mm

            Φ44

Feed XZ

Screw



mm



Taiwan

mm

X2508    Z3210

XZ axis Travel

mm

X 350

mm

Z 350

Linear

Taiwan

mm

X 30    Z35

Accuracy

positionaI accuracy



0.01

Repositioning Accuracy



0.003

Tail Stock

sleeve travel

mm

100

Tailstock taper



MT4

Tool  Holder







6 station electric tool holder

set

Tool size:20X20



dimensions (length x width x height)



1980X1550X1750mm

Weight



1960kg







Standard configuration:

ü  GSK 980D-L

ü High speed linear guidway

ü  Manual 3 jaw chuck

ü  4 station tools carrier

ü  Auto lubrication system

ü  Lighting system

ü  Cooling system

ü  380V 3 phase(if your local have special request  pls let us know)





Option configuration For TNC-350L
:



ü  6 /8 station electrice tool holder

ü  Auto feeder system

ü  Pneumatic chuck

ü  Hydrualic chuck

 ü  Chip conveyor
