Product Details
Place of Origin: | China | After-sales Service Provided: | Engineers available to service machinery overseas | Condition: | New |
Product Description
50-3000 tons per day Cement Production Line Equipment for sale
Main Materials: Limestone, Clay, Gypsum, Fly Ash, Slag
We provide the full range service including design, manufacturing, and installation. We design and manufacture equipment for new type dry method cement production line, for which the capacity varies from 50t/d to 3000t/d
OUR ADVANTAGE
1. High Efficiency
Cement production line adopts advanced technology and equipment to raise technical level and to ensure design indexes. New five-stage cyclone pre-heater system, high efficiency air girder grate cooler, multi-passage pulverized coal burner, Davison heat temperature fan, jet pulse dust collector, as well as chain-board elevator, chain conveyor adopted in this production line can ensure that the technology is advanced compared to other production lines with the same scale.
2. Saving Energy
Measures have been taken to save energy and reduce consumption. Using chain-board elevator and air slides, reliability of the system is enhanced and conveying energy consumption is decreased.
3. Environmental protection
Effective measures have been taken to guarantee strict environment protection standards. Different efficient dust collectors are set at all dust producing points according to different characteristics of waste gas.
4. High degree of automation
There is no manual operation in the process of mill running, which realizes the automatic control with long-term, stable, effective, makes milling process more stable, realizes fine work of production.
PRODUCTION TECHNOLOGY
Mined limestone is delivered to the crusher for crushing by the belt conveyor, limestone after crushing ,clay, iron powder etc will be ground into powder by ball mill or vertical mill, and then transported by air delivery chute to raw meal homogenization silo for storing and further material mix. Raw meal shall get into the preheating decomposition system after homogenization where decomposition rate is about 95%, and raw meal is calcined into clinker in the rotary kiln, the formation of clinker. Clinker, gypsum and mixture is ground into qualified fineness cement in the cement mill. Powder classifier is adopted to adjust the fineness of cement, realizing energy saving production. Cement packing machine and automatic loading machine are used for bagged cement delivery, and cement bulk device for cement canning leaving factory.
CONFIGURATION:
Dry process cement production line (25-200t/d)Configuration
Clinker capacity Equipment Parameters | 25t/d | 50 t/d | 100 t/d | 150 t/d | 200 t/d | |
Rotary kiln | Specification | Φ1.4×33m | Φ1.6/1.9×36m | Φ2.2×45m | Φ2.5×50m | Φ3×60m |
Capacity | 1t/h | 2t/h | 4t/h | 6t/h | 8t/h | |
Calcination Temperature (℃) | 1450 | 1450 | 1450 | 1450 | 1450 | |
Raw mill | Specification | Φ1.2×4.5m Open circuit | Φ1.5×5.7m Open circuit | Φ1.83×6.1m Open circuit | Φ1.83×6.1m Closed circuit | Φ2.2×6.5m Closed circuit |
Capacity | 1.7t/h | 4.5t/h | 9t/h | 12t/h | 16t/h | |
Motor power | 55kW | 130kW | 210kW | 210kW | 310kW | |
Cement mill | Specification | Φ1.2×4.5m Open circuit | Φ1.5×5.7m Open circuit | Φ1.83×6.1m Open circuit | Φ1.83×6.1m Closed circuit | Φ2.2×6.5m Closed circuit |
Capacity | 1.4t/h | 3.5t/h | 6.5t/h | 8t/h | 12t/h | |
Motor power | 55kW | 130kW | 210kW | 210kW | 310kW |
New dry process cement production line (300-1500t/d) configuration
Clinker Capacity Parameters | 300t/d | 700 t/d | 1000 t/d | 1500 t/d | |
Pre-heater | C1 | 2-Φ2500 | Φ3500 | Φ4800 | 2-Φ4000 |
C2 | Φ3600 | Φ4800 | Φ4800 | Φ5800 | |
C3 | Φ3600 | 2-Φ3700 | Φ5200 | Φ5800 | |
C4 | Φ3600 | Φ4800 | Φ5200 | Φ6200 | |
C5 | Φ3600 | Φ4800 | Φ5200 | Φ6200 | |
Pre-calciner |
Specification | Φ2200 | Φ2800 | Φ4800 | Φ5200 |
Rotary kiln | Specification | Φ2.8×44m | Φ3×48m | Φ3.2×50m | Φ3.5×54m |
Capacity | 12.5t/h | 30t/h | 42t/h | 63t/h | |
Calcination temperature (℃) | 1450 | 1450 | 1450 | 1450 | |
Raw mill |
Specification |
Vertical roller mill Φ1700
| Dry mill Φ3.2×7+1.8m | Dry mill Φ3.5×10m | HRM2800 Vertical roller mill |
Capacity | 30t/h | 50t/h | 85t/h | 130~160t/h | |
Motor power | 400kW | 1000kW | 1250kW | 1250kW | |
Cement mill | Specification | Φ2.4×13m Open circuit | Φ3×11m Closed circuit | Φ3.2×11m Closed circuit | Φ4.2×13.5m Closed circuit |
Capacity | 22t/h | 42t/h | 64t/h | 95t/h | |
Motor power | 800kW | 1250kW | 1400kW | 3550kW |
