Cheap portal frame 40 ton hydraulic press machine
The products are mainly made of high strength steel welded by tempering vibration aging treatment,rack design by finite element analysis,with high rigidity, high accuracy.
To ensure that the small amount of deformation characteristics of the machine,the table can be moved up and down,greatly expanding the height of the machine to open
and close,easier to use. Special custom table can be moved back and forth. Battery valves of two manual valves and electric valves, customers can develop different options
according to the height of the cylinder stroke can be customized according to customer requirements.
The goal is to provide the most economical hydraulic machine hydraulic machine for your process, the product is suitable for metal and nonmetal materials (watches,metal
products, bicycles, motorcycles, tableware, kitchenware, automotive, electronics, rubber, wheel, buttons, gold and silver jewelry , ceramics, powder metallurgy,etc.) of the
pressing process, the goal of hydraulic machine can also be used for stamping plastic material molding work.
Specification |
20TA |
20TB |
40TA |
40TB |
60TA |
60TB |
80TA |
80TB |
100TA One Step |
100TA Two Step |
Liquid working pressure(MPa) |
18 |
18 |
23 |
23 |
30 |
30 |
31.5 |
31.5 |
31.5 |
31.5 |
Travel (mm) |
200 |
200 |
200 |
200 |
200 |
200 |
240 |
300 |
240 |
240 |
Gantry span(mm) |
420 |
420 |
520 |
520 |
520 |
520 |
520 |
720 |
520 |
520 |
Working table size(mm) |
360*400 |
360*400 |
400*460 |
400*460 |
400*460 |
400*460 |
500*450 |
700*450 |
500*500 |
500*500 |
Motor power (KW) |
2.2 |
3 |
3 |
5.5 |
3 |
5.5 |
5.5 |
5.5 |
5.5 |
5.5 |
Pump displacement (ml/r) |
6 |
10 |
5 |
10 |
5 |
10 |
10 |
25 |
10 |
25 |
Descent speed (mm/s) |
12 |
21 |
6.5 |
14 |
6 |
12 |
9 |
23 |
7.5 |
19 |
Return speed (mm/s) |
19 |
32 |
9.5 |
19 |
8 |
16 |
13 |
34 |
10 |
25 |
Net weight (KG) |
240 |
240 |
370 |
370 |
380 |
380 |
860 |
880 |
1200 |
