Professional Manufacturer QK1327 CNC Pipe Threading Lathe Machine
The CNC pipe threading machine is developed for the oil field pipe thread turning and it is suitable for all types of pipe threads turning. The machine also can be used as general CNC lathes to machining complex shapes,like shaft sleeve, disc-type parts.
Pipe Threading CNC Lathe QK1327 Specification:
Items |
Lathe specifications |
Specifications |
Technical specifications |
Maximum diameter of lathe bed (mm) |
Φ800 |
Maximum tactical diameter of sliding plate (mm) |
Φ560 |
|
Maximum work-piece length (mm) |
1000 |
|
|
Main drive |
Form |
Main motor servo stepless |
Rank of spindle speed |
No grade |
|
Range of spindle speed(r/min) |
50-220rpm |
|
Hole diameter of spindle (mm) |
Φ280 |
|
The maximum diameter of the tube |
Φ275mm |
|
Power of main motor (KW) |
11KW(servo) |
|
|
Feeding system |
Maximum route of knife rest (mm) |
X:410 Z:1150 |
Speed of quick-travel (mm/min) |
X:3000 Z:4000 |
|
Resetting accuracy |
X:0.012 Z:0.016 |
|
Precision of work piece |
IT6-IT7 |
|
Surface roughness |
Ra1.6 |
|
|
Tailstock |
Sleeve diameter of tailstock (mm) |
Φ100 |
Sleeve trip of tailstock (mm) |
250 |
|
Cone hole taper tailstock’s sleeve |
MT5 |
|
Knife rest |
Standard configuration |
Four-station vertical electrical knife rest |
Alternative configuration |
Horizontal Six-station electrical knife rest |
|
Restting accuracy (mm) |
0.01 |
|
Length of section of knife handle (mm) |
30×30 |
|
|
Machine size weight |
Length*width*height |
3600×1850×1910 |
Net weight (Kg) |
5900Kg |
Pipe Threading CNC Lathe QK1327 features:
| Double chuck | Big spindle |
| Servo main motor | Taiwan ball screw |
| High efficiency | -- |
QK1327 Characters:
1, We set up TRB (tapered rolling bearings) on this lathe to increase the rigidity of the spindle.
2, The spindle bore is very large and set up double chucks both front and back and you can choose electric chucks as you like.
3, The surface of the slide rail of the bed is treated by the super audio quench, which can be endurable and wear-resisting. The slide rail f saddle is treated by wear-resisting layer coated, to avoid the crawling.
4, Stepless spindle speed controlled by servo,low-torque,high-speed precision
5, Set up self lubrication system, and easy to maintain.
QK1327 Standard configuration:
| CNC System:GSK-980TDc | 3 jaw manual double chuck |
| 4 station tool | Manual tailstock |
| Lighting system | Cooling system |
| Automatic lubrication system | 3 phase 380v 50Hz |
QK1327 Optional configuration:
| Siemens system /Fanuc system | Hydraulic chuck/ pneumatic chuck |
| 6-piece electric tool post/8- piece electric tool post | Optional max workpiece length 1500/2000/2500/3000mm |
1.Q:Can we pay by L/C?
A:Yes, we can do T/T, L/C etc.
2.Q: What is your payment terms?
A:Our payment term is 30% T/T in advance, 70% T/T before shipment.It is negotiable.
3.Q: What is your delivery time?
A:Usually, one machine takes 15-20 days. If we have in stock, we can arrange
shipment as soon as we receive the payment.
4.Q: Can we go to your factory and learn how to use the machine?
A:We sincerely welcome you come to our beautiful city. The training is free. It would
be great honor to us.
5.Q:Can you arrange training in our place after we bought your machine?
A: We can arrange oversea training. Buyers will be responsible to the costs.
6.Q:How many Voltage ? How many Phases 1 or 3? How many hertz (Hz)? of your
machine?
A:Our standard is 3 phase, 380V, 50/60Hz. All can be customer made.
7.Q: Do you have CE certification?
A:Yes, we have CE certification, machine quality is guaranteed.
8.Q: Is your company a factory or trading company?
A:We are factory and have more than 18 years production experience.
9.Q: How can I get the quotation?
A:You can send the inquiry on , or send email to us. It is better if you can
tell what is your detailed requests. We will reply to you within 1 hour.
10.Q:About your cnc machining center, I want to know if they can install the 4th axis.
A:Our cnc machining center can support the 4th axis. You can tell us the working
table size or the travel of X,Y,Z axis of machining center you need. We will give
you a recommendation about machine model.
