China machines , Good metal engraving machine
- 1000 per Month
- T/T Credit Card
-
4 axis machine, cnc engraving machine wholesale
-
Cnc for mold making, mini cnc milling machine with price
-
Cnc Engraving Machine for mould making, mini cnc engraving machine with price
-
CNC Machine Price List mould, mini desktop cnc milling for metal
-
Mini cnc milling mahine for Aluminium DC6060B, Air Condition Cooling CNC Mold Milling Machine
-
Industrial Milling Machine With One Year Maintenance Miniature Programming Cnc Machining
Product Details
| Brand Name: | KAIBOCNC | Place of Origin: | Zhejiang, China | Certification: | CE, ISO9001, ISO14001 |
| After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 1 Year | Weight: | 4200Kg |
| Application: | Iron, Aluminum, Wood | Rated Power: | 12Kw | Condition: | New |
| Engraving Speed: | 8m/min | Dimensions: | 2200*1800*2200mm | Milling Cutter Diameter: | 3.17-16mm |
| Feeding Height: | 1m | Main Axle Rotational Speed: | 24000rpm |
Product Description
China engraving machines for sale, hot sale metal engraving machine price
WELCOME TO KAIBOCNC: www.kaibocnc.en.china.cn
| SPECIFICATION/MODEL | DC6060B |
| Positioning accuracy | 0.01/300mm |
| Repeat positioning accuracy | ±0.005mm |
| X,Y,Z Axis Travel | 600×600×260mm |
| Table Size | 615×600mm |
| Z to space height | 530mm |
| Max. Loading | 300kg |
| Engraving processing Max. power consumption | 380v/220v/12kw |
| Spindle Motor Power | 5.5kw |
| X/Y/Z Axis Motor | 850w/850w/850w |
| Spindle Speed | 24000rpm |
| Max. Engraving speed | 10m/min |
| Tool Holder | Er25 (¢3.17-¢16) |
| Servo Motor | AC servo motor |
| Weight | 4000kg |
| Dimensions | 2290×1630×2200mm |
| CNC Controller System | Syntec 21MA |
| Standard Accessories | Linear Guides HG30-30 Hiwin/Taiwan |
Ball Screw 2505 Hiwin/Taiwan | |
Servo Motor 850w YASKAWA/Japan | |
Servo Motor Drives 850w YASKAWA/Japan | |
| High-speed Spindle 4kw Bohua or Xingchen / China | |
Spindle Inverter 5.5kw Inovance/China | |
Electronic Hand-Wheel EHDW-BA5S-1 Yuanzhan/Taiwan | |
Spindle Bearing SKF/Germany | |
Electronic System Schneider/Germany | |
| Water Gun | |
| Oil Coolant Chiller |
Pictures of Machine
Packed In Wooden Case, Standard packing For Engraving Machine
Customer Service
v Kaibo guarantees continuous and ongoing technical support for all of our products, and an technical enquiry of our machines can be replied within 24 hours.
v The warranty period of Kaibo's machine tools is 12 months from the date of completion of installation and comissioning.
After-sales Service
v Technician available for training and installation at customer's company.
v Internet service by sending emails and Videos,communicating online or calling. English Software.
1. With over 21 years manufacturing experience of CNC Machines, Over 50 Core Engineers are growing up with factory over 20years.
2. Each Machine is strictly in accordance with ISO and CE. KAIBOCNC has been named China famous brand, designated as the national standard setter by GB.
3. Quality Assurance, Timely delivery, Quick Service. Each year produce over 2000pcs,360 staffs,26 after-service teams.
