CC61250 series heavy duty lathe machine
- 100 Set / Sets per Month
- Dalian/Tianjing/Shanghai/Qingdao China
- T/T Credit Card
Product Details
Brand Name: | LFM | Place of Origin: | Liaoning, China | Model Number: | CC61250 heavy duty lathe machine |
After-sales Service Provided: | Engineers available to service machinery overseas | Condition: | New |
Product Description
CC61250 series heavy duty lathe machine
Such heavy duty lathe machine has following features:
1. width of bed 2050mm with 4 guideways;
2. big spindle bore: 160mm;
3. for heavy and supper large workpiece: turning, threading and so on;
Specifications | Unit | Parameter | Parameter | Parameter | Parameter |
Swing over Bed | mm | 2500 | 2500 | 2500 | 2500 |
Max. swing over carriage | mm | 2000 | 2000 | 2000 | 2000 |
Max. length of work piece | mm | 2000/3000/ 4000/5000 | 6000/8000/ 10000/12000 | 14000/16000 | 18000/20000 |
Width of bed With flat 4 guideways | mm | 2050 | 2050 | 2050 | 2050 |
Supporting weight between centers | T | 63 | 63 | 63 | 63 |
Spindle taper bore | mm | 160; 1:4 | 160; 1:4 | 160; 1:4 | 160; 1:4 |
Spindle Speed | rpm | 0.63 to 125, 2 steps | |||
Torque of faceplate | KN.m | 95 | 95 | 95 | 95 |
Max.cutting force of tool post | KN | 90 | 90 | 90 | 90 |
Size of tool holder | mm | 70x70 | 70x70 | 70x70 | 70x70 |
Travel of cross slide | mm | 800 | 800 | 800 | 800 |
Travel of tool post | mm | 600 | 600 | 600 | 600 |
Feedding range in longitudinal & cross slide | mm/min | 0.5TO 500 in stepless | |||
Rapid traverse of longitudinal & cross slide | mm/min | 4,000 | 4,000 | 4,000 | 4,000 |
Taper hole of tailstock sleeve | mm | 160; 1:4 | 160; 1:4 | 160; 1:4 | 160; 1:4 |
Dia of quill in tailstock | mm | 500 | 500 | 500 | 500 |
Movement of quill in tailstock: | mm | 200 | 200 | 200 | 200 |
Traverse speed of motorized tailstock | mm/min | 2,500 | 2,500 | 2,500 | 2,500 |
Power of main motor with adjusting speed device | KW | DC 110 | DC 110 | DC 110 | DC 110 |
