N Series HD Small Pixel LED Video Wall,HD LED Video Wall,Small Pixel LED Display
Item: 600*337.5*85 HD Small Pixel LED Video Wall.
Applications: Control Room, Stage , TV Stations, Meeting Room.
Certificates: FCC, CE, EMC, LVD.
Services: 5 Years Warranty
Small Pixel 16:9 LED Screen Specification | ||||
Item |
N Series |
N Series |
Not Available |
Not Available |
Pixe Pictch |
1.25mm |
1.56mm |
1.875mm |
2.5mm |
Scan Mode |
1/30 Scan |
1/24 Scan |
1/30 Scan |
1/30 Scan |
Pixe Per Sq.m |
640,000 Pixel |
409,600 Pixel |
284,444Pixel |
160,000 Pixel |
Led encapsulation |
SMD1010 |
|||
Maintenance methods |
Front/Rear Service Both |
|||
Cabinet Material |
Die Casting Aluminum |
|||
Module Size(W*H) |
160*180mm |
|||
Cabinet Size(W*H*D) |
640*360*58mm |
|||
Refresh Rate |
3840hz |
|||
Color temperature |
10000K ±500（Adjustable） |
|||
Grey Scale |
16bits |
|||
Cabinet Weight |
7.4KG/Pieces |
|||
Brightness(Nits/㎡) |
1000nits |
|||
Average Power Consumption |
100Watt/Pieces |
|||
Max Power Consumption |
200Watt/Pieces |
|||
IP Protection |
IP43 |
|||
Operating Temperature |
-10°C to 40°C |
|||
Working Voltage |
110-240Volt(50-60hz) |
|||
Hot Sale LED Video Wall, which include Outdoor Advertising Screens, Indoor Rental LED Screen, Floor Standing LED Display, See-Through LED Display, HD LED Vedio Panel. Low price, high quality. All LED Video Display provides 5 years warranty service.
If you want to know more product information, please click here
