HQ400-3AN HQ400-3BN HQ400-3V Lathe and Milling Machine Combination Lathe Milling
HQ400-3AN HQ400-3BN HQ400-3V Lathe and milling machine Combination lathe milling
Product main technical specifications:
Specifications | HQ400-3AN | HQ400-3BN | HQ400-3V | |||
Turning | Swing over bed | 420 mm | ||||
Distance between centers | 400 mm | |||||
Max. longitudinal travel | 380 mm | |||||
Max. cross travel | 120 mm | |||||
Taper of spindle | M.T.3 | |||||
Spindle hole | 20mm | |||||
Step of spindle speed | 7 | 7 | Variable speed | |||
Range of spindle speed | 160-1360 r.p.m | 0-600 r.p.m 600-1800 r.p.m | ||||
Barrel travel | 70 mm | |||||
Barrel taper | M.T.3 | |||||
Metric thread range | 0.7-2mm | |||||
Inch thread range | 7-30T.P.L | |||||
Longitudinal range of automatic feeding | 0.088-0.28mm/r | |||||
Cross range of automatic feeding | / | / | / | |||
Drilling & Milling | Max.drilling capacity | 15 mm | ||||
Worktable size | 200*150 mm | |||||
Max.end mill capacity | 20 mm | |||||
Max.face mill capacity | 63 mm | |||||
Spindle travel | 85 mm | |||||
Headstock travel of up and down | 80 mm | |||||
Spindle taper | M.T.3 | |||||
Step of spindle speed | 14 | 14 | Variable speed | |||
Range of spindle speed | 117-1300r.p.m | 0-660 r.p.m 660-2030 r.p.m | ||||
Swivel angle of headstock | ±360° | |||||
Motor | Motor power | 0.55kw | 0.55kw | 1.1kw | ||
Shipping data | Packing size | 1032*580*1000mm | ||||
N.weight/G.weight | 185kg/220kg | |||||
Loading amount | 44pcs/20container | |||||

Tengzhou Luzhong Machine Tool Co., Ltd. is a large-scale manufacturing enterprise with glorious chievement and long history .Founed in 1992 ,company covers an area of 30 thousand square meters, the construction covers area of 250 thousand square meters.
Our main products are : CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machine ,Drilling Machine ,Milling Machine and others metal cutting machine tools .All the products above have passed CE ,ISO ,SGS ,TUV certificates .

Machine Model: HQ400-3A HQ400-3B HQ400-3L Combination lathe milling machine
Type of package: Plywood case
Packaging size: 1030*580*1070 mm 1132*580*1070mm(one set in one case)
N.W./G.W.:180/215KGS 180kg/215kg 185kg/226kg

1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
