CJM320 Mini Small Hobby Bench Metal semi automatic lathes
- 100 Set / Sets per Month
- Any Port in china
- T/T Credit Card
- CJM320B Bench Lathe Machine Price Horizontal Turning lathe Machine
- CJM250 China Mini Lathe Machine for Sale Mini Lathe Small Mini Lathe
- Mini Metal Bench Lathe Machine CJM320B Mini Lathe Price
- small lathe machine 320mm horizontal type CJM320B mini metal lathe
- Small Mini Lathe Machine CJM250 Manual Bench Metal Mini Lathe
- Metal Lathe Cutting Machine Tools CA6140 Manual Lathe Machines for Sale
Product Details
Brand Name: | Luzhong Machine | Place of Origin: | Shandong, China | After-sales Service Provided: | No overseas service provided |
Condition: | New |
Product Description
CJM320 Mini Small Hobby Bench Metal semi automatic lathes
Product description:
1.The mini lathemachine adopts full gear drive, double rod operation, no need to replace the hanging wheel
can meet the needs of a variety of different kinds of knife and a variety of pitch.
2.Vertical and horizontal feed adopts interlocking mechanism, safety is good.
3.The mini lathe machine tool uses two mountains and two moment rail, high frequency quenching, high
accuracy, high rigidity, good abrasion resistance.
Product main technical Specifications:
Specifications | Units | CJM320B |
Lathe bed maximum turning diameter | mm | 320 |
Skateboard largest workpiece turning diameter | mm | 600/800 |
Maximum workpiece diameter rotary table | mm | 200 |
Spindle hole diameter | mm | 38 |
Taper of spindle | mm | No.5 |
Spindle | mm | 80—1600r.p.m 12 |
The maximum horizontal stroke of cutter | mm | 160 |
The knife frame maximum longitudinal travel | mm | 100 |
Processing metric thread number | mm | 22 |
Processing range of metric threads | mm/r | 0.2-7 |
The processing module thread number | mm/r | 21 |
The processing module thread range | mm | 0.2-3.5 |
Processing diameter pitch threads number | kg | 31 |
Processing pitch thread range | mm | 8-120 1/n″ |
Longitudinal feed spindle turret at every turn | mm | 0.1-1.4 |
The transverse feed amount per turn spindle turret | mm | 0.045-0.6 |
The maximum amount of movement of the tailstock sleeve | mm | 80 |
Taper the tailstock sleeve | mm | No.3 |
Electric machinery | w | 750W/380V/50HZ |
Gross / net weight | kg | 450/390 |
Dimensions (length * width * height) | mm | 1370×685×1360 |
Packing size (length * width * height) | mm | 1470×770×1470 |
C series Lathe Machine | CA Series Lathe Machine |
CJM320B Mini Lathe Machine | CW6180E Lathe Machine |
Tengzhou Luzhong Machine Tool Co., Ltd. is a large-scale manufacturing enterprise with glorious chievement and long history .Founed in 1992 ,company covers an area of 30 thousand square meters, the construction covers area of 250 thousand square meters.
Our main products are : CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machine ,Drilling Machine ,Milling Machine and others metal cutting machine tools .All the products above have passed CE ,ISO ,SGS ,TUV certificates .
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
