SIMENSE automatic lathe MT3040 china cnc lathe machine
Product features:
TC series CNC lathe is designed with high strength, rigidity and with advanced machine structure, defense, and security. The machine adopt the high rigidity cast iron, base and lathe bed monolithic structure, high precision through-hole structure, vibration resistance designed and high range spindle motor. The bearings and feeding screw adopt the world famous brand, equipped witd multi-position tool post, tools are easily changed and changed fast with high precision. CNC system can adopt FANUC 0i-TD,FANUC 0i-Mate TD,SIMENSE 810D,SIMENSE 820D,DASEN 3i,and other brand can also be chosen the hydraulic parts, lub rication parts,chuck adopt the high quality productionas well.
The outlook is designed well, working panel can be easily operated, full cover. Comparing with other same type, our product owns higher precision and performance and big power.
Product main technical specifications:
Specifications |
Unit |
MT3040 |
Bed incline |
. |
30 |
piece lengh |
mm |
900 |
Cutting capacity over bed |
mm |
400 |
Cutting capacity over support |
mm |
450 |
Chuck size |
|
A2-8 |
Spindle power |
kw |
7.5 |
Spindle speeds |
rpm |
3500 |
Spindle bore |
mm |
72 |
Dia.of bar through spindle bore |
mm |
60 |
Rapid feed speed |
m/min |
18 |
Xtravel |
mm |
230 |
Z travel |
mm |
900 |
Tailstock sleeve diameter |
mm |
65 |
Tailstock sleeve travel |
mm |
100 |
Tailstock travel |
mm |
780 |
Tailstock taper |
- |
MT4 |
Positioning accuracy |
mm |
±0.008(X)±0.011(Z) |
Repositioning accuracy |
mm |
±0.003(X)±0.005(Z) |
Machine dimensions(L*w*h) |
mm |
2200*1750*1880 |
Weight |
T |
2.5/2.8 |
Tengzhou Luzhong Machine Tool Co., Ltd. is a large-scale manufacturing enterprise with glorious chievement and long history . Founed in 1992 ,company covers an area of 30 thousand square meters, the construction covers area of 250 thousand square meters.
Our main products are : CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machine ,Drilling Machine ,Milling Machine and others metal cutting machine tools .All the products above have passed CE ,ISO ,SGS ,TUV certificates .
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
