Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E

Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E thumbnail-1
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E thumbnail-2
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E thumbnail-3
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E thumbnail-4
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E thumbnail-5
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E thumbnail-6
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E thumbnail-7
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E photo-1
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E photo-2
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E photo-3
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E photo-4
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E photo-5
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E photo-6
Easy Operation Swiss Type CNC Automatic Turning Lathe H-F203E photo-7
US$ 20,000 - 30,000 MOQ: 50 Sets
Key Specifications
Get Latest Price
Brand Name:
HIENCE
Place of Origin:
Shandong, China
After-sales Service Provided:
Overseas service center available
Contact Supplier Request Quote Chat Now
Horizontal Lathe Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Ningbo.etc
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HIENCE
Place of Origin Shandong, China
After-sales Service Provided Overseas service center available
Condition New
Product Description
                                            Description
Unit
Specification



Main
spindle
Stroke
mm
75 (Standard) ; 120 (Optional);
210 (Optional)
(All travel synchronised guide sleeve)
Max. RPM
rpm
100~12000
Max. turning diameter
mm
20
Additional positive brake
°
Infinite
Main spindle bore diameter
mm
22



Tooling
Number of O.D tools
ea
5
OD tool size
mm
12X12
Number of front work tools
ea
4
Max. drilling diameter(front)
mm
7(ER11)
Max. tapping diameter(front)
mm
M6(ER11)








Motor
Number of cross driven tools
ea
4
Cross driven tools Max .rpm
rpm
5000
Max. drilling diameter( radial direction)
mm
8(ER16)
Max. tapping diameter( radial direction)
mm
M6(ER16)
Maximum diameter of saw blade milling tools( radial direction)
mm
30(ER16)
Main spindle motor
kw
2.2/3.7
Cross driven tools motor
kw
0.75
Servo motor
kw
(X,Z,Y)0.75
Lubricant motor
kw
0.25
Coolant pump
kw
0.85
Rapid traverse rate
m/min
X/Y 30,Z24



Others
Coolant tank capacity
L
100
Lubrication tank capacity
L
10
Center height
mm
1050
Dimensions(L×W×H)
mm
1750×910×1700
Machine weight
kg
1780
Power consumption
kw
7
CNC controller
Standard
LNC-T568
