CW6263B Metal Conventional Mini Lathe Cutting Tools Price

CW6263B Metal Conventional Mini Lathe Cutting Tools Price photo-1
CW6263B Metal Conventional Mini Lathe Cutting Tools Price photo-2
US$ 13,000 - 21,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
MEEKARE
Place of Origin:
Jiangsu, China
Model Number:
CW6263B
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Brand Name MEEKARE
Place of Origin Jiangsu, China
Model Number CW6263B
After-sales Service Provided Engineers available to service machinery overseas
Condition New
Product Description

CW6263B Metal Conventional Mini Lathe Cutting Tools Price

Technical Parameters:

Specification for China CW6263B Metal Conventional Mini Lathe Cutting Tools Price
Model
CW6263B
Guideway width (mm)
550
Max.swing over bed (mm)
630
Max.swing in gap (mm)
800
Available length in gap (mm)
300
Max. workpiece length (mm)
1500, 3000, 4000, 5000
Max.swing over carriage (mm)
350
Hole through spindle (mm)
Φ105
Taper of the tailstock
Mohs 5
Bed quenching hardness
HRC52
Quick travel speed of saddle (mm/Min)
 4000
Number of spindle speed changes
18 steps
Range of spindle speed changes (r/Min)
8~1000
Range and number of metric thread
1~240mm/ 50 kinds
Range and number of whitworth thread
14~1t.p.i (Tooth / inch)/ 26 kinds
Module thread range and number
0.5~120mm/ 53 kinds
Pitch thread range and number
28~1t.p.i(Tooth / inch)/ 24 kinds
Power of main motor (KW)
11
Processing workpiece accuracy
IT7
Workpiece surface roughness
Ra1.6

This sheet is only for reference, for detailed specification and technical data please refer to operation manual. Our company reserves the right of improving products' design and specifications without notice.

Photos
Company Show
What We Provide

- CNC Tapping Machine

- CNC Machining Center (Vertical, Horizontal, Gantry type)

- Lathe (Common, CNC)

- Milling Machine (Common, CNC)

- High Speed CNC Engraving and Milling Machine

- EDM Wire Cut Machine (Middle speed, Fast speed, Large taper)
- CNC Spark Machine
- EDM Small Hole Drilling Machine
- Other non-standard machine

Packing & Delivery

Package: Standard export plywood case, or as per customers’ requirements.
Before shipment, machines would be painted with rust-proof oil and packed with water-proof material very carefully. Machinery shall be packed in a way suitable for long distance ocean freight transportation and to change of climate, well protected against moisture and shocks.
