Aluminum Strip for Transformer
- 10 Ton / Tons per Month
- Qingdao
- T/T
- 30 days
- Anodized Aluminum Strips
- 3003 O aluminium strip for pex -al -pex pipe
- Aluminum Roll/strip/strip With Cheap Price 1060/3003/3004/5a06h112/5a05-0/5a05/5a06h112 For Perforate Panels, And Clean Plates
- Good Price Wholesale 1060/3003/3004/5a06h112/5a05-0/5a05/5a06h112 Insulation Aluminum Coil/strip/roll Hardness Large Stocks
- Aluminum Strip/coil/roll Factory 3003/3004/5a06h112/5a05-0/5a05/5a06h112/1060 Interior Applications For Fascias And Shop Fronts
- Aluminum Alloy Manufacturer Exterior Applications 5a06h112/1060/3003/3004/5a06h112/5a05-0/5a05 For Kitchens And Balconies
Product Details
Brand Name: | Gongyi Shengzhou Metal Products Co.,Ltd. | Place of Origin: | China | Model Number: | 1060 Aluminum Strip for Transformer |
Thickness: | 0.2mm-3.0mm | Width: | 20mm-1650mm | Application: | |
Temper: | O - H112 | Al (Min): | Alloy Or Not: | Is Alloy | |
Grade: | 1000 Series | Elongation (≥ %): |
Product Description
Specification of Aluminum Strip for Transformer
Material: pure aluminum 1060;
Temper: O;
Origin: Henan - Gongyi;
Executive standard: YS/T 713-2009.
Technical Parameters of 1060 Aluminium Strip for Transformer
Thickness: 0.2mm-3.0mm
Width: 20mm-1650mm
Resistivity: ≤0.028
Conductivity: ≥60%IACS
Conductivity is not less than 35.4m/(Ω·mm2)
Introduction of 1060 Aluminum Strip for Transformer
Transformer aluminum strip is the key raw material for the manufacture of transformer windings, which is the ribbon obtained by embossing aluminum ingots. Aluminum strip for transformer (aluminum strip for dry-type transformer) is made of high-quality pure aluminum. It has high conductivity, soft texture, smooth surface and no burr. It is an ideal material for producing dry-type transformers. In the production of aluminum strips for transformers, the requirement of many technical indexes such as electrical conductivity of aluminum strip and foil, burr curling, side bending, and surface quality are very high.
The 1060 transformer aluminum strip produced by Shengzhou Aluminum Industry have reached and exceeded the national standards in many technical parameters. The dry type transformer produced by the aluminum strip has the advantages of small volume, light weight, good insulation performance, flame retardant, no pollution, partial discharge, moisture resistance, stable and reliable operation, low noise and low maintenance cost. Mainly used in high-rise buildings, underground facilities, commercial centers, residential areas, hotels and coastal humid areas.
Select Material of Aluminum Strip for Transformer
1060 aluminum strips are generally used for dry-type transformers, which contains more than 99.6% aluminum, which is a common series in aluminum plate and strip family. The advantage of using this series of aluminum strips is that it is a commonly used series, the production process is simple, the technology is relatively mature, and the price has a huge price advantage compared to other high-grade alloy aluminum sheets. Its good elongation and tensile strength can fully meet the conventional processing requirements (stamping, stretching) and high formability. 1060 aluminum is industrial pure aluminum, with high plasticity, corrosion resistance, electrical conductivity and thermal conductivity, but the strength is low, heat treatment can not be strengthened, machinability is not good. It can be gas welded, hydrogen atom welded and contact welded, and is not easy to braze; it is easy to withstand various pressure processing and extension and bending.
Packaging of Aluminium Strip for Transformer
Description: The surface is smooth and scratch-free. The side can be 100% burr-free and better than national standards.
Packing: wooden pallet, inner diameter 300mm or 500mm.
Introduction of our company
Gongyi Shengzhou Metal Products Co.,Ltd. is a professional Aluminium Strip Suppliers and Aluminum Circles manufacturers,mainly supply Aluminum Circles, Aluminium discs, Aluminum Strip, Food Box Material Aluminum Foil, Aluminum Circles for Kitchenware etc. series of aluminum products, sincerely welcome everyone to visit.
Contact information:
/
MOBILE: +86.15137196538
Tel: +86.371.60266515
SKYPE: yoyo@cncablewire.com
Whatsapp: +86.15137196538
E-MAIL: yoyo@cncablewire.com
Contact Us
- Gongyi Shengzhou Metal Products Co.,Ltd.
- Contact nameYoyo
- AddressGongyi Zhengzhou,Henan
