Parameter table
1. High rigidity casting body
The main castings such as the main base, worktable, slide, column and machine head are made of high-grade cast iron. Through finite element analysis and calculation, the engineering requirements for rigidity multiplication and quality are achieved. Each casting is subjected to internal stress elimination treatment. To ensure long-term deformation, and excellent bending and torsional stress, to ensure long-term machine tool grinding accuracy.
2. Independent hydraulic system
Single-cylinder drive, with independent hydraulic system design, make the workbench with 7-25m/min multi-stage adjustable speed and low vibration characteristics, suitable for multi-purpose processing, use high quality oil seal made in Japan to ensure sliding Smooth and long life
3. High-precision ballistic spindle
Each grinding machine of our company adopts the design of Taiwan's original imported ballistic spindle, with CP4 Japanese original NSK precision angled ball bearing, V3 low vibration motor and dynamic balance, installed on the headstock to ensure the spindle The yaw control is within 0.002mm.
4. Automatic lubrication system
The use of a circulating central lubrication device provides optimum lubrication of the X, Y, and Z axis drive screws and sliding surfaces, and can recycle some of the non-recyclable waste oil, filter, and recycle lubrication. This is not only environmentally friendly, but also saves lubrication. The unnecessary expenditure of oil.
5. PLC electrical control system
LCD touch screen, soft key panel, various grinding conditions set at a glance, touch screen set a variety of grinding methods, simple and convenient operation. Easy to learn and understand, without professional training, its parameters are stored in flash memory, and there is no problem of data loss due to blackout.
6. Graphical operation panel
The operation panel box is fixed in design, the control is completely centralized on the operation panel, and it is ergonomic; the operation panel is of a graphic design, the function is clear at a glance, and the operation is easy to learn.
Parameter table
Standard package,wooden case. We are located in Kunshan city, close to Shanghai port, it is very convenient to transport.
For the love of God we promise customers as follow:
1. Our product quality warranty is one year, except for man-made damage,and consumables such as grinding wheel and wire rope
except also.
2. We also have technical support and online service, If you have any problems with the use or technical problems above, we have a dedicated engineer to solve the problem or give professional advice in 24hours.
MaAnShan Kuroda Intelligent Technology Co., Ltd. is Taiwan Yalita set up a grinding machine manufacturing base in the mainland market. The factory area is 12,000 square meters. We can complete the entire production process from design, manufacture and assembly. Processing equipment includes six large machining centers and two imported horizontal boring and milling centers. It is one of the precision grinding machines and CNC machine tool manufacturing bases in mainland China. It has technology research and new product development. Jiangsu high-tech enterprises, private high-tech companies We have passed ISO9000 2008 quality management certification EU product safety CE certification We have obtained 34 national new patents. Our company has six large gantry machining centers and two imported horizontal boring and milling centers. Large-scale laser laser cutting machine 1, CNC bending machine, plate gold spray water lines. With an annual output of more than 1000 grinders, CNC milling machine more than 1,000 units of the scale, sheet metal processing 5000 sets of assembly processing capacity. Plant area of 12,000 square meters 30 years of grinding industry experience, to provide you with one-stop grinding solutions!
We mainly produce precision surface grinding machines, centelless grinding machines, machining centers, and engaving and milling
Why choose Kuroda?
1. In the field of grinding, CNC grinding is a leading position in China. In the field of forming grinding, we have been adhering to the past 29 years and serving more than 5,400 customers.
2.Products from the development, design, manufacture, assembly of the entire production process are carried out between plants, with a complete production chain. Is your most reliable guarantee
