Home > Products > Manual surface grinder > universal cylindrical grinding machine
universal cylindrical grinding machine
- 50 Set / Sets per Month
- Shanghai port
- T/T Credit Card
Product Details
Brand Name: | Stute | Place of Origin: | Anhui, China | Type: | Cylindrical Grinding Machine |
Certification: | CE ISO | After-sales Service Provided: | No overseas service provided | Weight: | 1750KG |
Dimension(L*W*H): | 1800*1400*1450mm | Voltage: | 380V | Condition: | New |
Power(W): | 7.5kw | CNC or Not: | Normal | Max. Grinding Length: | 1000mm |
Max. Grinding Diameter: | 1mm-40mm |
Product Description
Precision centerless grinder specification
Vibrate to send to workpiece in the machine,and pull out the workpiece form machine front by mechanical device.
Automaticall unloader for machine tool can be designed according to the workpiece diameter and lenght.
Small diameter automatically workpiece unplader.
Ltems | SM-12 |
Grinding range(diameter) | Φ1mm-Φ40mm |
Grinding wheel size | Φ305*150*120mm |
Regulating wheel size | Φ205*150*90mm |
Grinding wheel speed | 1950RPM |
Regulating wheel motor | 0-320RPM |
Grinding wheel motor | 7.5HP |
Regualting wheel motor | 2.0KW |
Hydraulic pump motor | 1HP |
Coolant pump motor | 1/8HP |
Upper slide feed graduation | 3.5 mm per revolution 0.02mm/scale |
Upper silde micro feed graduation | 0.1mm per revolution 0.001mm/scale |
Lower silder feed graduation | 7mm per revolution 0.05mm/scale |
lower slider micro feed graduation | 0.2mm per revolution 0.001mm/scale |
Dressing device graduation | 1.5mm per revoltion 0.01mm/scale |
Regulating wheel title angle | ±5°--- -3° |
Regulating wheel swivel angle | ±5° |
Machine dimensions | 1800*1400*1450mm |
Package dimensions | 2350*1650*1770mm |
Net weight | 1750kg |
Gross Weight | 1900kg |
Standard accessories
1. Grinding wheel flange
2. Regulation wheel flange
3. Diamond tool
4. Work lamp
5. Blades wheel template
6. Flange extractor
7. Thrufeed standard work rest and blade
8. Infeed standard work rest and blande
9. Tool box and tools
10. Hydraulic tank
11. Coolant tank with pump
12. Standar electrical equipmen
Optional accessories
1. Vibratory parts feeder
2. Wheel balancing base
3. Manual parts feeder for infeed grinding
4. Work gigctor device
5. Hydrocyclone coolant filtering unit
6.Paper filter
7. Magnetic coolant separator
8. Feed-through device(plunge)
9. Feed-through device(belt)
10. Long workpieces received feeding device
11. Oil mist separator device
12. Precision oil temperature cooling device
