CK6180 Cnc Lathe Machine Price with Siemens 808d Controller
- Product Description
CK6180 Cnc Lathe Machine can be equiped with Siemens, Fanuc , Mitsubishi, KND, GSK, SYNTEC controller system.
All the two axis are the sliding (hard) rail kind . The structure and dimension of axis are compact and reasonable. Spindle is variable- frequency variable-speed droved by variable frequency motor through belt which can clamping various plate, shaft, and component all at once. The flat bed cnc lathe machine can complete the processing of recessing, groove, inner (outer) hole, spherical, R cone angle, curved shape, cone shape, end face, and the single or multiple thread processing for the metric/inch threads. It is applicable for multi and mass production, and can meet the processing demands for complex and high precision parts.
- Technical parameter
ITEM
|
CKNC6163
|
CKNC6180
|
CKNC61100
|
CKNC61125
|
Max.swing over bed
|
630mm
|
800
|
1000
|
1250
|
Max.swing over slide
|
350mm
|
480
|
600
|
850
|
cessing length
|
1500mm
|
1500/3000/6000
|
||
Guideway width of bed
|
550mm
|
660mm
|
||
X axis travel
|
400mm
|
520
|
625
|
|
Z axis travel
|
1000,1500,2000,3000mm |
|||
X/Z axis lead screw
|
4/7m/min
|
4/5m/min
|
||
X/Z axis rapid speed
|
0.025/0.03mm
|
|||
X/Z positioning precision
|
0.01/0.015mm
|
|||
X/Z repositioning precision
|
IT6-IT7
|
|||
Procecessing precision
|
0.01
|
|||
Surface roughness
|
Ra1.6
|
|||
Spindle speed range
|
Three steps frequency,40-125,110-350,290-950
|
Three steps frequency,15-500
|
||
Spindle head type
|
C11
|
|||
Dia.of spindle thru-hole
|
105mm
|
130mm
|
||
Spindle hole tapper
|
1:20(Metric system)120mm
|
(metric system)140mm 1:20
|
||
Chunk
|
320(12")optional 400,500mm |
400(16")
|
500(12")
|
|
Spindle motor power
|
11kw
|
11/15kw
|
15kw
|
|
Tool holder type
|
Electric 4 staions
|
|||
Turning tool size
|
30*30mm
|
35*35mm
|
||
Tailstock sleeve travel
|
250mm
|
|||
Tailstock sleeve dia
|
100mm
|
|||
Tailstock sleeve taper
|
Morse 5
|
Morse6
|
||
Controller
|
SIEMENS,FANUC,KND,GSK
|
|||
N.w
|
3600kg
|
3900KG
|
6000,8500,13500KG
|
|
Dimesion
|
3700*1500*1600mm
|
3700*1500*1600
|
4200*1920*1800(1.5M),4750*1920*1800(2M), 5750*1920*1800(3M) |
|
- Our Company
Jinan Hankui international trade co., ltd
Jinan Hankui international trade co., ltd is a CNC machine tools company, located in the beautiful capital Jinan city, integrated with manufacturing, processing and sales. It was set up by the former Jinan Machine tools factory employees. It has a subsidiary corporation Jinan HANKUI International Trade Co., Ltd. The plant area is about 10,000 square meters. We have a number of R&D persons and technicians who have more than 20 years experience of machine tool design and assembly. We have mastered the advanced machine tool technology and were dedicating to service customers domestic and abroad and welcomed deeply.
The main products are horizontal / vertical/ gantry machining center, flat / slant bed CNC tuning lathe, CNC vertical turning lathe etc. With superior equipment, advanced technology, detection devices, the imported parts from Taiwan, Japan, Germany etc., we can manufacture the high quality machine tools. And we also take over the metal products and spare parts machining in good quality.
With more than 10 years development, our products have occupied a large share in domestic and overseas market. Sales and services network have been established in many provinces and cities. With superior equipment, advanced technology, detection devices, we can take over all sort of standard and non-standard products manufacturing of all specifications in good quality. Our products have been sold to European countries, America, South East Asia and Middle East countries with high reputation.
- Certification
We have passed the ISO9001:2008, CE, SGS etc international quality management system authentication. "Honest and trust, Customer ahead, pursuit of excellent", we devoted to provide high quality performance CNC products and metal products to you. Welcome to visit our factory.
- Packing & Delivery
Packing Details : Packing by woodenbox or depend on request
Delivery Details : 7-45 days
- Our Service
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
- FAQ
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available, We need your machines running in order to keep your business running.
Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine
Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.OEM is acceptable
Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.
Q: What sales terms do you have?
A:T/T, L/C,West Union.
Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings or Video Support,
Q: Once machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.
Q: What do I need to offload my machine from the container?
A: You are not responsible for the offloading of your machinery, and it is recommended that you use a reputable rigging company.
Q: What kind of controls/Parts do you use on your machines?
A: AMS, OMRON, Schneider, Siemens, and ASK,ABBA,OPTIMA(ITALIA),HSD
Q: What is your delivery time?
A: Depending on the type of machine, duration of 10 days to 45 days from date of order.
Q: Do we receive any updates while machine is in the manufacturing process?
A: Yes.Regular updates on progress will be sent to you.
-
