CK6140 Wheel Rim Repair Automatic Bar Feeder Cnc Lathe
US$ 12,192 - 14,192
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HANKUI
Place of Origin:
Shandong, China
After-sales Service Provided:
Engineers available to service machinery overseas
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao for CK6140 Wheel Rim Repair Automatic Bar Feeder Cnc Lathe
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CKNC61100 Large Size Flat Bed Cnc Lathe Brand Famous in ChinaUS$ 45,000 - 63,000MOQ: 1 Set -
CK-32L Repair Universal Cutting Cnc Lathe MachineUS$ 14,781 - 15,559MOQ: 1 Set
-
CKNC61100 Taiwan Linear Guide Rail Cheap Cnc Lathe MachineUS$ 45,000 - 63,000MOQ: 1 Set
-
CKNC6180 Siemens 808d Price Servo Motor Lathe MachineUS$ 21,195 - 25,000MOQ: 1 Set
-
CK6136 4-Station Hydraulic and Electric Turret Mini CNC Milling Machine FrameUS$ 10,800 - 10,800MOQ: 1 Set
Brand Name
HANKUI
Place of Origin
Shandong, China
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
BSB011 CK6140 Wheel Rim Repair Automatic Bar Feeder Cnc Lathe
What is the Details of our Flat Bed CNC Lathe?
ITEM |
Parameter |
Unit |
CK6140 |
|
Processing Range |
Max.swing over bed |
mm |
400 |
Max.swing over slide |
mm | 230 |
|
Max. processing length |
mm | 750/1000 |
|
Feed |
Guideway Width of bed |
mm | 350 |
X axis travel |
mm | 220 |
|
Z axis travel |
mm | 750/1000 |
|
X/Z axis lead screw |
mm | 2505/3206 |
|
X/Z axis rapid speed |
m/min |
6/8 |
|
X/Z positioning precision |
mm |
0.02/0.03 |
|
X/Z repositioning precision |
mm |
0.012/0.016 |
|
Processing precision |
IT6-IT7 |
||
ellipticity |
mm |
0.01 |
|
Surface roughness |
Ra≤1.6
|
||
Spindle speed range |
50-3500 |
||
Spindle |
Spindle head type |
A2-6 |
|
Dia. Of spindle thru- hole |
mm |
66 |
|
Spindle hole tapper |
MT6 |
||
chunk |
mm |
200(8”) |
|
Spindle Motor power |
kw |
5.5 |
|
Tool Holder |
Tool holder type |
Vertical 4 stations (horizontal 6 stations)
|
|
Turning tool size |
mm |
25*25 |
|
Tailstock |
Tailstock sleeve travel |
mm |
120 |
Tailstock sleeve dia. |
mm |
60 |
|
Tailstock sleeve taper |
mm |
MT4 |
|
controller |
controller |
SIEMENS(standard), FANUC, KND, GSK (optional)
|
|
Dimesion |
N.W |
kg |
2200/2500 |
Dimension |
mm |
2500*1700*1700 2700*1700*1700 |
|
Product Picture
Product Pictures
Product Features
PRODUCT FEATURES
standard configuration |
| Full enclosed cover |
| One- piece body structure |
| 4-station electric tool post |
| Automatic lubrication |
| NSK spindle bearing of Japan |
| Manual chuck & tailstock |
| Optional configuration |
| Hydraulic Chuck & Tailstock |
| Electric 6/8-Station Turret |
| CNC Controller |
| SIEMENS |
| FANUC |
| KND |
| GSK |
| Mitsubishi |
| SYNTEC |
PACKING AND SHIPPING
| Packaging Detail: | High quality wooden case or According to the customer's requirements. |
| Delivery Detail: | Within 35 working days after receiving your deposit. |
| According to the customer's requirements. | |
Factory Show
FACTORY SHOW
FAQ
FAQ
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available, We need your machines running in orderto keep your business running.
Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine
Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.OEM is acceptable
Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.
Q: What sales terms do you have?
A: T/T, L/C,West Union.
Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings or Video Support,
Q: Once a machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.
Q: What do I need to offload my machine from the container?
A: You are not responsible for the offloading of your machinery, and it is recommended that you use a reputable rigging company.
Q: What kind of controls/Parts do you use on your machines?
A: AMS, OMRON, Schneider, Siemens, and ASK,ABBA,OPTIMA(ITALIA),HSD
Q: What is your delivery time?
A: Depending on the type of machine, duration of 10 days to 45 days from date of order.
Q: Do we receive any updates while machine is in the manufacturing process?
A: Yes.Regular updates on progress will be sent to you.
